Ortustech NEW 3.5 inch LCD Display Panel COM35H3827XLC for Handheld & PDA
| Parameter |
Specification |
| Model Number |
COM35H3827XLC |
| Manufacturer |
Ortustech |
| Panel Type |
TFT-LCD (Thin Film Transistor) |
| Screen Size |
3.5 inches |
| Resolution |
320 (RGB) × 240 pixels (QVGA) |
| Aspect Ratio |
4:3 |
| Active Area |
70.08 (W) × 52.56 (H) mm |
| Outline Dimensions |
76.9 (W) × 63.9 (H) × 2.8 (D) mm (Typical) |
| Pixel Arrangement |
RGB Vertical Stripe |
| Display Mode |
Transmissive, Normally White |
| Color Support |
262K (18-bit color) / 16.7M (24-bit color) |
| Interface |
18-bit / 24-bit RGB Parallel Interface |
| Backlight Type |
LED (Light Emitting Diode) |
| Supply Voltage |
3.3V (Logic) |
| Operating Temperature |
-20°C to 70°C (Wide Temperature) |
| Storage Temperature |
-30°C to 80°C |
The COM35H3827XLC is engineered for applications requiring a compact, durable display with a standard QVGA interface. Its specific applications include:
- Industrial Control & Automation:
- HMI (Human Machine Interface): Small control panels for factory machinery and robotics.
- Handheld PDAs: Industrial portable data terminals used in logistics, warehousing, and inventory management.
- Medical Equipment:
- Display screens for portable medical diagnostic devices, patient monitors, and handheld medical instruments.
- Consumer & Commercial Electronics:
- Home Appliances: Control interfaces for high-end washing machines, coffee machines, or smart home hubs.
- Security Systems: Monitors for video intercoms and access control panels.
- Automotive & Transportation:
- Secondary displays in vehicle dashboards or rear-seat entertainment units.
Ortustech
FAQ
Q: How long will I receive my goods ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX
Q:Can you give me a discount if I need a large quantity of ?
A:Of course!If you make a large order, we will give you a discount.
Q:Can I pay my order via credit card ?
A:Yes!you can use your credit card through your Paypal account.
- Q: May I ask what kind of packaging you use?
A: We use anti-static packaging and shock-resistant packaging.Anti-static packaging: Ensure that the packaging materials used comply with ESD standards, including anti-static bags and foam.Shock-resistant packaging: Use custom foam and sturdy outer boxes to ensure that they can pass through regular transportation tests (such as dropping and vibration).So the goods arrive at your hands in perfect condition.
Q: Do you conduct tests before shipment?
A: Yes, we strictly follow 100% pre-shipment testing procedures.Our testing process is standardized to ensure that every LCD panel sent to you is in compliance with specifications and is fully functional.
