AUO NEW 43 inch LCD Display Panel P430QVN01.0 for Industrial Digital Signage
| Category |
Parameter |
Specification |
| Basic Info |
Manufacturer / Model |
AUO / P430QVN01.0 |
|
Panel Size / Type |
43-inch / a-Si TFT-LCD, Liquid Crystal Module |
|
Production Status |
Mass Production |
| Structure |
Resolution / Pixel Layout |
3840(RGB)×2160 (UHD) / RGB Vertical Stripe |
|
Active Area (H×V) |
941.184 × 529.416 mm |
|
Outline Dimension (H×V×T) |
963.7 × 552 × 28.9 (Max.) mm |
|
Aspect Ratio / Weight |
16:9 (H:V) / 9.50 Kgs (Typ.) |
|
Surface Treatment |
Haze 44%, Hard coating (3H) |
| Optical |
Brightness / Contrast |
500 cd/m² (Typ.) / 4000:1 (Typ.) |
|
Viewing Angle (CR≥10) |
89/89/89/89 (Typ.) (Full viewing angle) |
|
Display Mode / Response Time |
AMVA3, Normally Black / 8 ms (Typ. G to G) |
|
Display Colors / Color Depth |
16.7M / 8-bit |
| Electrical |
Operating Frequency |
60Hz |
|
Power Consumption |
83.7W (Typ.) |
| Backlight |
Lamp Type / Position |
WLED / Side LED |
|
Lifetime |
70,000 hours (Min.) |
| Environment |
Operating Temperature |
0 ~ 50 °C |
|
Storage Temperature |
-20 ~ 60 °C |
The P430QVN01.0 is a high-performance 43-inch UHD panel featuring high brightness (500 nits), an extremely high contrast ratio (4000:1), and wide viewing angles thanks to its AMVA3 technology. Based on these optical characteristics, it is specifically suitable for:
- High-End Commercial Displays: Ideal for digital signage, advertising machines, and information kiosks in bright environments due to its 500 cd/m² brightness and anti-glare surface treatment.
- Professional Monitoring Systems: The 4K UHD resolution and wide viewing angles make it excellent for security control rooms, traffic monitoring stations, and industrial control dashboards where detail and multi-angle visibility are crucial.
- Medical Imaging Displays: The high contrast ratio (4000:1) allows for better differentiation of dark details, making it suitable for certain medical diagnostic monitors or hospital information displays.
- Public Information Terminals: Used in airports, train stations, or museums for interactive maps and schedule boards, benefiting from its durable hard coating and long backlight lifespan (70,000 hours).
