Ortustech NEW 4.3 inch LCD Display Panel COM43H4N90ULC for Industrial
| Parameter |
Specification |
| Model Number |
COM43H4N90ULC |
| Manufacturer |
Ortus Technology / AOSHiTE |
| Panel Type |
TFT-LCD (Transflective) |
| Screen Size |
4.3 inches |
| Resolution |
480 (RGB) × 800 pixels (WVGA) |
| Orientation |
Portrait (Vertical) |
| Display Mode |
Half-Transmissive / Half-Reflective |
| Active Area |
~60.0 (W) × 100.8 (H) mm (Approximate) |
| Pixel Arrangement |
RGB Vertical Stripe |
| Color Support |
16.7M (24-bit color) |
| Interface |
RGB Parallel / TTL |
| Backlight Type |
LED (Low Power Consumption) |
| Special Features |
Sunlight Readable, High Contrast |
| Operating Temperature |
-20°C to 70°C (Wide Temperature) |
| Lifespan |
> 50,000 hours |
The COM43H4N90ULC is specifically engineered for outdoor and high-reliability industrial applications where visibility in bright sunlight is critical. Its specific applications include:
- Industrial Handheld Terminals:
- Rugged PDAs and data loggers used in logistics, warehousing, and field services where screen visibility outdoors is required.
- Outdoor Control Systems:
- Control panels for agricultural machinery, construction equipment, and outdoor monitoring stations.
- Automotive & Transportation:
- Dashboard displays or control units for vehicles operating in high-glare environments.
- Golf & Sports Equipment:
- Handheld GPS devices or launch monitors (as indicated by specific demo data showing golf metrics like "Club Speed" and "Launch Angle").
- IoT & Smart Devices:
- Battery-powered portable devices requiring low power consumption and high readability.
Ortustech
FAQ
Q: How long will I receive my goods ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX
Q:Can you give me a discount if I need a large quantity of ?
A:Of course!If you make a large order, we will give you a discount.
Q:Can I pay my order via credit card ?
A:Yes!you can use your credit card through your Paypal account.
- Q: May I ask what kind of packaging you use?
A: We use anti-static packaging and shock-resistant packaging.Anti-static packaging: Ensure that the packaging materials used comply with ESD standards, including anti-static bags and foam.Shock-resistant packaging: Use custom foam and sturdy outer boxes to ensure that they can pass through regular transportation tests (such as dropping and vibration).So the goods arrive at your hands in perfect condition.
Q: Do you conduct tests before shipment?
A: Yes, we strictly follow 100% pre-shipment testing procedures.Our testing process is standardized to ensure that every LCD panel sent to you is in compliance with specifications and is fully functional.
