TIANMA NEW 15.6 inch LCD Display Panel P1560FHF2MA00 for Industrial
| Parameter |
Specification |
| Model |
P1560FHF2MA00 |
| Manufacturer |
TIANMA (Tianma Microelectronics) |
| Screen Size |
15.6 inch |
| Resolution |
1920 × 1080 (FHD) |
| Brightness |
1000 cd/m² (Typ.) |
| Operating Temperature |
-30°C to 85°C |
| Storage Temperature |
-30°C to 85°C |
| Interface |
LVDS (2 channels, 8-bit), 30 pins |
| Backlight |
WLED (White LED), Side-entry |
| Backlight Life |
50,000 hours |
| Aspect Ratio |
16:9 |
| Active Area |
344.16 × 193.59 mm |
| Outline Dimension |
363.8 × 215.9 × 11 mm |
| Surface Treatment |
Haze (Anti-glare) |
The P1560FHF2MA00 is specifically targeted at industrial and specialized commercial sectors.
Key application areas include:
- Medical & Healthcare: Integrated into medical imaging devices, patient monitoring systems, and diagnostic equipment where high clarity and reliability are critical.
- Industrial Automation: Used in Human-Machine Interfaces (HMIs), factory control panels, and machinery displays that operate in harsh environments.
- Outdoor & Transportation: Suitable for outdoor kiosks or vehicle-mounted displays that require high brightness for sunlight readability and wide temperature tolerance.
- Commercial Display: Applied in high-end digital signage and public information displays.
TIANMA
FAQ
Q: How long will I receive my goods ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX
Q:Can you give me a discount if I need a large quantity of ?
A:Of course!If you make a large order, we will give you a discount.
Q:Can I pay my order via credit card ?
A:Yes!you can use your credit card through your Paypal account.
- Q: May I ask what kind of packaging you use?
A: We use anti-static packaging and shock-resistant packaging.Anti-static packaging: Ensure that the packaging materials used comply with ESD standards, including anti-static bags and foam.Shock-resistant packaging: Use custom foam and sturdy outer boxes to ensure that they can pass through regular transportation tests (such as dropping and vibration).So the goods arrive at your hands in perfect condition.
Q: Do you conduct tests before shipment?
A: Yes, we strictly follow 100% pre-shipment testing procedures.Our testing process is standardized to ensure that every LCD panel sent to you is in compliance with specifications and is fully functional.
