Kyocera (Optrex) 8.4 inch LCD Display Panel T-55786GD084J-LW-AEN for Industrial NEW
| Parameter |
Specification |
| Model Number |
T-55786GD084J-LW-AEN |
| Manufacturer |
Kyocera Display (Optrex) |
| Display Type |
a-Si TFT-LCD, Transmissive Module |
| Screen Size |
8.4 inches (Diagonal) |
| Resolution |
800 (RGB) × 600 pixels (SVGA) |
| Pixel Pitch |
0.213 mm (H) × 0.213 mm (V) |
| Pixel Arrangement |
RGB Vertical Stripe |
| Active Area (AA) |
170.4 mm (W) × 127.8 mm (H) |
| Outline Dimensions |
Approx. 199.5 mm (W) × 149.0 mm (H) × ~12.5 mm (D) |
| Brightness |
Typically 600 ~ 800 cd/m² (High Brightness)
(Ensures readability in well-lit industrial environments) |
| Contrast Ratio |
600:1 (Typical) |
| Viewing Angle |
80/80/80/80 (Min.) (Left/Right/Up/Down) |
| Backlight Type |
White LED (Mercury-free, Long Life) |
| Interface |
TTL or LVDS (Low Voltage Differential Signaling)
(The 'E' in AEN often denotes a specific connector style, e.g., a specific pitch header or cable assembly) |
| Color Depth |
16.7 Million Colors (24-bit) or 262k Colors (18-bit) |
| Operating Temperature |
-30°C to +80°C (Wide Temperature Range) |
| Storage Temperature |
-40°C to +90°C |
| Surface Treatment |
Anti-Glare (AG), Hard Coating (3H)
(Prevents reflections and protects against scratches) |
| RoHS Compliance |
Yes |
| Application Grade |
Industrial, Medical, Transportation, Military |
FAQ
Q: How long will I receive my goods ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX
Q:Can you give me a discount if I need a large quantity of ?
A:Of course!If you make a large order, we will give you a discount.
Q:Can I pay my order via credit card ?
A:Yes!you can use your credit card through your Paypal account.
- Q: May I ask what kind of packaging you use?
A: We use anti-static packaging and shock-resistant packaging.Anti-static packaging: Ensure that the packaging materials used comply with ESD standards, including anti-static bags and foam.Shock-resistant packaging: Use custom foam and sturdy outer boxes to ensure that they can pass through regular transportation tests (such as dropping and vibration).So the goods arrive at your hands in perfect condition.
Q: Do you conduct tests before shipment?
A: Yes, we strictly follow 100% pre-shipment testing procedures.Our testing process is standardized to ensure that every LCD panel sent to you is in compliance with specifications and is fully functional.
