AUO NEW 7.0 inch LCD Display Panel C070VAN02.7 for Industrial
| Parameter |
Specification |
| Model Number |
C070VAN02.7 |
| Screen Size |
7.0 inch |
| Display Type |
a-Si TFT-LCD, Transmissive |
| Resolution |
800 × 480 (WVGA) |
| Brightness |
400 cd/m² (Typ.) |
| Contrast Ratio |
1300:1 (Typ.) |
| Viewing Angles |
89°/89°/89°/89° (Typ.) (CR≥10) |
| Response Time |
11/19 (Max.) (Tr/Td) (ms) |
| Display Colors |
262K / 16.7M (6-bit / 6-bit + Hi-FRC) |
| Optical Mode |
AHVA, Normally Black |
| Interface |
LVDS (1 channel, 6/8-bit) |
| Signal Voltage |
3.3V (Typ.) |
| Operating Temperature |
-20°C to +70°C |
| Dimensions |
166.6 × 107 × 7.0/10.0 (Typ./Max.) mm |
The C070VAN02.7 is a 7.0-inch industrial LCD module manufactured by AUO (友達). It features an AHVA panel technology, providing high brightness and wide viewing angles, making it suitable for various industrial applications. The module features a WLED backlight with a typical lifetime of 70,000 hours.
This industrial LCD is designed for use in various control and automation systems, including:
- CNC Systems: Compatible with major systems such as FANUC, Siemens, and Mitsubishi.
- General Industrial Equipment: Used in manufacturing machinery, control panels, and automation systems.
- Medical Devices: Employed in diagnostic equipment and monitoring systems.
- ATMs & Kiosks: Utilized in automated banking machines and self-service terminals.
- Handheld Devices: Incorporated into portable industrial data terminals and PDAs.
AUO
FAQ
Q: How long will I receive my goods ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX
Q:Can you give me a discount if I need a large quantity of ?
A:Of course!If you make a large order, we will give you a discount.
Q:Can I pay my order via credit card ?
A:Yes!you can use your credit card through your Paypal account.
- Q: May I ask what kind of packaging you use?
A: We use anti-static packaging and shock-resistant packaging.Anti-static packaging: Ensure that the packaging materials used comply with ESD standards, including anti-static bags and foam.Shock-resistant packaging: Use custom foam and sturdy outer boxes to ensure that they can pass through regular transportation tests (such as dropping and vibration).So the goods arrive at your hands in perfect condition.
Q: Do you conduct tests before shipment?
A: Yes, we strictly follow 100% pre-shipment testing procedures.Our testing process is standardized to ensure that every LCD panel sent to you is in compliance with specifications and is fully functional.
