G104VN01 V1 10.4inch AUO lcd panel for industrial

SKU: G104VN01 V1
Model P/N : G104VN01 V1
Diagonal Size: 10.4"
Panel Type: a-Si TFT-LCD,
Resolution :640(RGB)×480, VGA  76PPI
Pixel Format: RGB Vertical Stripe
0.0 (0 Reviews)
0 Sold
$80.00 $78.00
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity:
-
+
  • G104VN01 V1 10.4inch 640(RGB)×480 TFT lcd panel in stock
  • G104VN01 V1 10.4inch 640(RGB)×480 TFT lcd panel in stock
  • G104VN01 V1 10.4inch 640(RGB)×480 TFT lcd panel in stock
  • G104VN01 V1 10.4inch 640(RGB)×480 TFT lcd panel in stock
  • G104VN01 V1 10.4inch 640(RGB)×480 TFT lcd panel in stock
  • G104VN01 V1 10.4inch 640(RGB)×480 TFT lcd panel in stock
  • G104VN01 V1 10.4inch 640(RGB)×480 TFT lcd panel in stock
  • G104VN01 V1 10.4inch 640(RGB)×480 TFT lcd panel in stock
1/1
  • G104VN01 V1 10.4inch 640(RGB)×480 TFT lcd panel in stock
  • G104VN01 V1 10.4inch 640(RGB)×480 TFT lcd panel in stock
  • G104VN01 V1 10.4inch 640(RGB)×480 TFT lcd panel in stock
  • G104VN01 V1 10.4inch 640(RGB)×480 TFT lcd panel in stock
  • Description
The AUO G104VN01 V1 is a 10.4-inch industrial-grade TFT-LCD module from AU Optronics. It is specifically engineered for demanding environments, offering excellent optical performance, an ultra-wide operating temperature range, and a long-life LED backlight. Its design makes it ideal for harsh industrial applications, including HMI (Human-Machine Interface) and other professional equipment .

Feature Specification
Model G104VN01 V.1
Availability In Stock (Ready for Immediate Shipment)
Screen Size 10.4 inches
Active Area 211.2 (W) × 158.4 (H) mm
Resolution 640 (RGB) × 480 pixels (VGA)
Aspect Ratio 4:3
Display Type a-Si TFT-LCD, Transmissive
Brightness (Typ.) 450 cd/m² (Typ.)
Contrast Ratio (Typ.) 700:1 (Typ.) (TM)
Viewing Angle (L/R/U/D) 80° / 80° / 80° / 80° (CR≥10, typ.)
Color Gamut (Typ.) 262K/16.2M   45% NTSC
Backlight Type WLED
Backlight Life 50,000 hours (typical)
Interface LVDS (1 ch, 6/8-bit) , 20 pins Connector
Supply Voltage 3.3V (Logic), 5.0V or custom (Backlight)

Typical Applications

  • Industrial HMI: Control panels, CNC machine interfaces, factory automation .

  • Transportation & Energy: Railway signal terminals, vehicle-mounted displays, and petroleum exploration equipment.

  • Outdoor Equipment: Field monitoring stations and ruggedized terminals.

  • Medical Equipment: Specialized diagnostic displays requiring wide temperature tolerance.
