Lumineq NEW 5.7 inch LCD Display Panel EL320.240.36 HB CCB for Industrial
| Parameter |
Specification |
| Model Number |
EL320.240.36-HB CCB |
| Display Technology |
Electroluminescent (EL) |
| Screen Size |
5.7 inch (Diagonal) |
| Resolution |
320 x 240 pixels (QVGA) |
| Color / Emission |
Monochrome (Yellow emission) |
| Brightness |
150 cd/m² (Typical) |
| Contrast Ratio |
90:1 (Typical) |
| Viewing Angle |
89/89/89/89 (Wide viewing angle) |
| Response Time |
Max 1 ms (No motion blur) |
| Refresh Rate |
120 Hz |
| Operating Temperature |
-40°C to +85°C |
| Storage Temperature |
-40°C to +105°C |
| Supply Voltage |
5V / 12V (Typical) |
| Interface |
Parallel Data (1ch, 4-bit) |
| Backlight/Life |
Self-luminous (No backlight tube), 50,000+ hours |
Due to its "solid-state" structure, lack of liquid crystals (which can freeze or boil), and self-luminous nature, this display is specifically engineered for extreme environments where standard LCDs would fail.
1. Military & Aerospace (Defense)
- Ruggedized Handhelds: Used in portable military radios and data terminals because it can survive high G-force shocks (up to 200G) and drops.
- Avionics: Cockpit displays where wide temperature ranges (-40°C to +85°C) are critical for high-altitude or high-speed operations.
2. Industrial Control & Automation
- Factory Floor HMIs: Ideal for control panels in unheated warehouses or hot factory environments.
- Oil & Gas Equipment: Used in drilling monitors where equipment is exposed to extreme outdoor weather conditions.
3. Transportation & Automotive
- Vehicle Terminals: On-board computers for forklifts, mining trucks, and agricultural machinery that operate in direct sunlight (high brightness/contrast) and freezing temperatures.
4. Medical & Scientific
- Field Medical Devices: Portable diagnostic equipment used in field hospitals or ambulances requiring instant-on capability without warm-up time.
5. Public Safety
- Emergency Response: Handheld devices for firefighters or police, as the screen remains readable in bright sunlight and functions immediately in freezing conditions.
Lumineq
FAQ
Q: How long will I receive my goods ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX
Q:Can you give me a discount if I need a large quantity of ?
A:Of course!If you make a large order, we will give you a discount.
Q:Can I pay my order via credit card ?
A:Yes!you can use your credit card through your Paypal account.
- Q: May I ask what kind of packaging you use?
A: We use anti-static packaging and shock-resistant packaging.Anti-static packaging: Ensure that the packaging materials used comply with ESD standards, including anti-static bags and foam.Shock-resistant packaging: Use custom foam and sturdy outer boxes to ensure that they can pass through regular transportation tests (such as dropping and vibration).So the goods arrive at your hands in perfect condition.
Q: Do you conduct tests before shipment?
A: Yes, we strictly follow 100% pre-shipment testing procedures.Our testing process is standardized to ensure that every LCD panel sent to you is in compliance with specifications and is fully functional.
