TX54D14VC0CAA | JDI 21.3” UXGA IPS
TX54D14VC0CAA is a 21.3-inch UXGA (1600×1200) IPS-Pro TFT-LCD module by JDI, featuring 820 cd/m² high brightness, 1100:1 contrast ratio, 85° super-wide viewing angle, WLED backlight, dual-channel LVDS interface, and 0°C~+50°C operating temperature for medical imaging, industrial HMI, and high-end display applications.
| Parameter Item |
Specification Details |
| Part Number |
TX54D14VC0CAA |
| Manufacturer |
JDI (Japan Display Inc.) |
| Display Size |
21.3 inch, landscape, 4:3 |
| Resolution |
1600(RGB)×1200 pixels (UXGA), 94 PPI |
| Technology |
a-Si TFT-LCD, IPS-Pro, normally black, transmissive |
| Active Area |
432 × 324 mm |
| Outline Dimension |
460.6 × 362 × 12 mm |
| Pixel Pitch |
0.27 × 0.27 mm |
| Brightness |
820 cd/m² (typ.) |
| Contrast Ratio |
1100:1 (typ., CR≥10) |
| Viewing Angle |
85°/85°/85°/85° (L/R/U/D) |
| Display Colors |
16.7M colors (75% CIE1931) |
| Backlight |
WLED (3 strings), lifespan ≥ 50,000 hours, with driver |
| Interface |
LVDS (2 channels, 8-bit), 30-pin connector |
| Supply Voltage |
12.0 VDC (typ.) |
| Refresh Rate |
60 Hz |
| Response Time |
12/10 ms (Tr/Td, typ.) |
| Operating Temperature |
0°C ~ +50°C |
| Storage Temperature |
-20°C ~ +60°C |
| Touch Screen |
Without touch (customizable) |
| Surface Treatment |
Anti-glare (AG), non-glare |
| Weight |
3.0 kg (typ.) / 3.4 kg (max) |
| Certifications |
RoHS compliant |
| Status |
Active, mass production |
