KOE/HITACHI/JDI NEW 5.7 inch LCD Display Panel TX14D11VM1CBD REV.A for Industrial
| Parameter Category |
Specification |
| Model |
TX14D11VM1CBD |
| Brand |
Hitachi (HITACHI) |
| Display Type |
a-Si TFT-LCD, Liquid Crystal Module |
| Screen Size |
5.7 inch |
| Resolution |
320(RGB) × 240 (QVGA) |
| Display Color |
262K (6-bit) |
| Brightness |
280 cd/m² (Typical) |
| Display Mode |
TN, Normally White, Transmissive |
| Pixel Arrangement |
RGB Vertical Stripe |
| Aspect Ratio |
4:3 |
| Viewing Area |
115.2 × 86.4 mm |
| Outline Dimensions |
167(H) × 109(V) mm |
| Weight |
220 g (Typical) |
| Backlight Type |
CCFL (1 piece), No Driver |
| Interface Type |
40-pin CMOS (1 channel, 6-bit), Terminal |
| Supply Voltage (VDD) |
3.3V (Typical) |
| Operating Temperature |
-20°C ~ 70°C |
| Storage Temperature |
-30°C ~ 80°C |
| Touch Panel |
4-wire Resistive Touch Screen |
The TX14D11VM1CBD REV.A is a ruggedized industrial LCD module featuring an integrated touch screen, designed for reliable operation in harsh environments.
1. Industrial Control & Automation
This module is widely used in Industrial Equipment and Human-Machine Interfaces (HMI). It serves as a primary display and control unit for Numerical Control (NC) systems and automation machinery, compatible with major control brands such as FANUC, Siemens, Mitsubishi, KND, and GSK.
2. Medical Instruments
It is frequently integrated into Medical Devices and diagnostic equipment. The module's wide operating temperature range (-20°C to 70°C) and resistive touch technology ensure stable and precise performance in clinical settings.
3. Automotive & Monitoring Systems
The TX14D11VM1CBD is suitable for Automotive Navigation systems and Monitoring Devices, providing a durable and interactive visual interface for mobile and stationary surveillance applications.
4. Self-service Terminals
It is also applied in Handheld PDAs and Self-service Kiosks (such as ATMs), where the integrated touch screen provides a robust interface for user interaction in public and industrial spaces.
