KOE/HITACHI/JDI NEW 3.5 inch LCD Display Panel TX09D70VM1CDA REV.D for Industrial
| Parameter Category |
Specification |
| Model |
TX09D70VM1CDA |
| Brand |
Hitachi (HITACHI) |
| Display Type |
a-Si TFT-LCD |
| Screen Size |
3.5 inch |
| Resolution |
240(RGB) × 320 (QVGA) |
| Display Color |
262K (6-bit) |
| Brightness |
100 cd/m² (Typical) |
| Display Mode |
TN, Normally White, Transmissive |
| Pixel Arrangement |
RGB Vertical Stripe |
| Aspect Ratio |
3:4 (Portrait) |
| Viewing Area |
53.64 × 71.52 mm |
| Outline Dimensions |
64.0 × 86.0 × 7.47 mm |
| Weight |
40.0 g (Typical) |
| Backlight Type |
WLED, Side-type, Integrated LED Driver |
| Interface Type |
CMOS (1 channel, 6-bit), 40-pin Terminal |
| Supply Voltage (VDD) |
3.3V (Typical) |
| Operating Temperature |
-20°C ~ 70°C |
| Storage Temperature |
-30°C ~ 80°C |
The TX09D70VM1CDA is a compact, high-brightness TFT-LCD module designed for integration into various portable and industrial devices.
1. Industrial Equipment
This module is commonly used in Industrial Control Panels and Numerical Control (NC) systems. Its robust design and wide operating temperature range make it suitable for use in CNC machines and other automation systems where reliability is paramount.
2. Medical Instruments
It is frequently integrated into Medical Devices as a display unit for patient monitoring and diagnostic equipment. The module's ability to function in a wide temperature range ensures stable performance in diverse clinical environments.
3. Portable and Embedded Devices
The TX09D70VM1CDA is well-suited for Handheld PDA systems and Automotive Navigation units. Its 3.5-inch size and portrait orientation are ideal for compact, battery-powered devices that require clear graphical displays.
4. Self-service Terminals
It is also utilized in ATM Systems and various Self-service Kiosks, providing a durable and clear visual interface for banking and retail services.
