AUO NEW 18.5 inch LCD Display Panel M185XW01 V.D for Industrial
| Parameter |
Specification |
| Panel Brand |
AU Optronics (AUO) |
| Panel Model |
M185XW01 V.D |
| Panel Size |
18.5 inch |
| Panel Type |
a-Si TFT-LCD, Transmissive |
| Resolution |
1366(RGB)×768 [WXGA] |
| Pixel Layout |
RGB Vertical Stripe |
| Display Area |
409.8 (W) × 230.4 (H) mm |
| Overall Dimension |
430.4 (W) × 254.6 (H) × 10.4 (D) mm |
| Surface Treatment |
(Matte), Hard coating (3H) |
| Brightness |
250 cd/m² (Typ.) |
| Contrast Ratio |
1000:1 (Typ.) (TM) |
| Viewing Angle |
85/85/80/80 (Typ.)(CR≥10) |
| Display Mode |
TN, Normally White |
| Response Time |
3.6 / 1.4 ms (Typ.)(Tr/Td) |
| Display Colors |
16.7M (6-bit + FRC), 68% (CIE1931) |
| Backlight Type |
10S4P WLED, 30K hours (No driver) |
| Refresh Rate |
60Hz |
| Signal Interface |
LVDS (1 ch, 8-bit), 30 pins, Connector |
| Supply Voltage |
5.0V (Typ.) |
| Operating Temp. |
0 ~ 50 °C |
| Storage Temp. |
-20 ~ 60 °C |
The M185XW01 V.D is a reliable and cost-effective display panel widely used in various consumer and industrial electronics. Its specific applications include:
- Desktop Monitors: As a standard WXGA (1366x768) panel with a 16:9 aspect ratio, it is highly suitable for entry-level to mid-range 18.5-inch computer monitors used in offices, schools, and internet cafes.
- All-in-One (AIO) PCs: Due to its slim profile (10.4mm thickness) and integrated LED backlight, it serves as an excellent display component for compact All-in-One desktop computers.
- Industrial Control Panels: With its wide operating temperature range (0~50°C) and durable matte surface treatment (Hard coating 3H), this panel can be embedded into Human-Machine Interfaces (HMIs) or industrial automation equipment requiring stable visual feedback.
- Digital Signage & Kiosks: The panel's high contrast ratio (1000:1) and consistent brightness make it applicable for indoor digital advertising displays, self-service kiosks, and information terminals.
- Home Entertainment Displays: It can also be utilized in small-sized smart TVs or as a secondary display screen for home multimedia systems.
AUO
FAQ
Q: How long will I receive my goods ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX
Q:Can you give me a discount if I need a large quantity of ?
A:Of course!If you make a large order, we will give you a discount.
Q:Can I pay my order via credit card ?
A:Yes!you can use your credit card through your Paypal account.
- Q: May I ask what kind of packaging you use?
A: We use anti-static packaging and shock-resistant packaging.Anti-static packaging: Ensure that the packaging materials used comply with ESD standards, including anti-static bags and foam.Shock-resistant packaging: Use custom foam and sturdy outer boxes to ensure that they can pass through regular transportation tests (such as dropping and vibration).So the goods arrive at your hands in perfect condition.
Q: Do you conduct tests before shipment?
A: Yes, we strictly follow 100% pre-shipment testing procedures.Our testing process is standardized to ensure that every LCD panel sent to you is in compliance with specifications and is fully functional.
