LM1260A01-1C 3.5 inch LCD Display Screen For Industrial

Name: LM1260A01-1C 3.5 inch LCD Display Screen For Industrial
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: LM1260A01-1C
Price: 73 USD
Availability: InStock

SKU: LM1260A01-1C

Model: LM1260A01-1C
Size: 3.5 inch
Resolution: 240×320 (QVGA)
Display Type: TFT-LCD, Transmissive

0.0 (0 Reviews)

0 Sold

~~$75.00~~ $73.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

LM1260A01-1C 3.5 inch LCD Display Screen For Industrial

Parameter	Details
Model	LM1260A01-1C
Size	3.5 inch
Resolution	240×320 (QVGA)
Display Type	TFT-LCD, Transmissive
Brightness	250–300 cd/m² (Typ.)
Contrast Ratio	300:1 ~ 400:1
Viewing Angle	±60°(H)/±40°(V)
Color Depth	16-bit (65,536 colors)
Backlight	LED, lifespan ≥20,000 hours
Interface	Parallel RGB (18-bit)
Operating Temp	-10°C ~ +60°C
Storage Temp	-20°C ~ +70°C
Touch Panel	Integrated glass touch screen
Application Device	Intermec CK3X/CK3R handheld terminals

Applications

Handheld Data Terminals: Specifically designed for Intermec CK3X/CK3R industrial mobile computers, used in logistics, warehousing, and inventory management.
Industrial Scanners & PDAs: Ideal for barcode scanners, portable data collectors, and rugged handheld devices requiring compact, durable displays.
Medical Portable Devices: Suitable for patient monitors, diagnostic equipment, and portable medical instruments needing small-size, low-power displays.
Smart Industrial Controllers: Applied in injection molding machine screens, industrial control panels, and intelligent display terminals for factory automation.
Automotive & Navigation: Used in industrial vehicle dashboards, onboard monitoring terminals, and small-size navigation displays.
