LM32019T2R Sharp 5.7 inch 320×240 LCD Display Screen For Industrial

Name: LM32019T2R Sharp 5.7 inch 320×240 LCD Display Screen For Industrial
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: LM32019T2R
Price: 48 USD
Availability: InStock

SKU: LM32019T2R

Model: LM32019T2R
Manufacturer:Sharp
Size: 5.7 inch
Resolution: 320×240 (QVGA)
Display Type: STN-LCD, Monochrome

0.0 (0 Reviews)

0 Sold

~~$50.00~~ $48.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

LM32019T2R Sharp 5.7 inch 320×240 LCD Display Screen For Industrial

Parameter	Details
Model	LM32019T2R
Manufacturer	Sharp
Size	5.7 inch
Resolution	320×240 (QVGA)
Display Type	STN-LCD, Monochrome, Blue Mode, Transmissive
Brightness	100 cd/m² (Typ.)
Contrast Ratio	6:1 (Typ.)
Viewing Angle	40°/40°/25°/40° (L/R/U/D, CR≥2)
Backlight	1×CCFL, 15,000 hrs lifespan, no driver
Interface	Parallel (4-bit), 12-pin FPC
Operating Temp	0°C ~ +45°C
Storage Temp	-25°C ~ +60°C
Outline Dimension	166 × 109 × 7.5 mm (W×H×D)
Active Area	115.17 × 86.37 mm
Pixel Pitch	0.36 × 0.36 mm
Weight	Approx. 160 g
Features	High brightness, blue mode, compact size

Applications

Industrial Control Panels: For factory automation, PLC systems, and CNC machinery requiring reliable monochrome displays.
Medical Devices: Suitable for patient monitors, diagnostic equipment, and portable medical instruments needing low-power, high-contrast screens.
Test & Measurement Equipment: Used in oscilloscopes, signal generators, and industrial meters for clear data visualization.
Marine & Rugged Environments: Applied in ship control panels, offshore equipment, and industrial vehicles due to wide temperature tolerance.
Telecom Infrastructure: For base station monitoring, network devices, and industrial communication terminals requiring stable performance
