Hitachi/KOE LMG7131PNFL 3.5 inch 240 × 200 LCD Panel Screen For Industrial

Name: Hitachi/KOE LMG7131PNFL 3.5 inch 240 × 200 LCD Panel Screen For Industrial
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: LMG7131PNFL
Price: 108 USD
Availability: InStock

SKU: LMG7131PNFL

Model: LMG7131PNFL (KOE/Hitachi)
Diagonal Size: 3.5 inches
Resolution: 240 × 200 pixels
Display Type: Industrial FSTN-LCD, Monochrome

0.0 (0 Reviews)

0 Sold

~~$110.00~~ $108.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

Hitachi/KOE LMG7131PNFL 3.5 inch 240 × 200 LCD Panel Screen For Industrial

Parameter	Details
Model	LMG7131PNFL (KOE/Hitachi)
Diagonal Size	3.5 inches
Resolution	240 × 200 pixels
Display Type	Industrial FSTN-LCD, Monochrome (Negative)
Active Area	71.0 × 59.0 mm (approx.)
Outline Dimension	85.0 × 68.0 × 7.5 mm (approx.)
Brightness	150 cd/m² (typical)
Contrast Ratio	12:1 (typical)
Viewing Angle	40°/40°/30°/50° (CR ≥ 5)
Backlight	WLED (lifetime ≥ 50,040 hours)
Interface	CPU/Parallel (14 pins)
Supply Voltage	3.3 V / 5 V (selectable)
Operating Temperature	-20°C to +70°C
Storage Temperature	-30°C to +80°C
Features	Compact size, low power consumption, rugged industrial design, ESD protection, wide temperature tolerance

Applications

Industrial Handheld Devices: Portable data collectors, industrial PDAs, and field test equipment.
Medical Equipment: Portable diagnostic tools, patient monitors, and medical instrument displays.
Factory Automation: Small PLC panels, injection molding machine screens, and CNC equipment displays.
Smart Handheld Terminals: Industrial control terminals and human-machine interface (HMI) systems.
Legacy Industrial Upgrades: Direct replacement for older KOE/Hitachi 3.5" FSTN panels in existing systems.
