LG Display LP140WU1-SPA1 14 inch 1920×1200 LCD Panel Display For Industrial

SKU: LP140WU1-SPA1
Model P/N: LP140WU1-SPA1
Diagonal Size: 14"
Panel Type: a-Si TFT-LCD, LCM
Pixel Number: 1920(RGB)×1200, 16:10, WUXGA
Pixel Format: RGB Vertical Stripe
0.0 (0 Reviews)
0 Sold
$46.00 $45.00
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity:
-
+
  • LG Display LP140WU1-SPA1 14 inch 1920×1200 LCD Panel Display For Industrial
  • LG Display LP140WU1-SPA1 14 inch 1920×1200 LCD Panel Display For Industrial
  • LG Display LP140WU1-SPA1 14 inch 1920×1200 LCD Panel Display For Industrial
  • LG Display LP140WU1-SPA1 14 inch 1920×1200 LCD Panel Display For Industrial
  • LG Display LP140WU1-SPA1 14 inch 1920×1200 LCD Panel Display For Industrial
  • LG Display LP140WU1-SPA1 14 inch 1920×1200 LCD Panel Display For Industrial
1/1
  • LG Display LP140WU1-SPA1 14 inch 1920×1200 LCD Panel Display For Industrial
  • LG Display LP140WU1-SPA1 14 inch 1920×1200 LCD Panel Display For Industrial
  • LG Display LP140WU1-SPA1 14 inch 1920×1200 LCD Panel Display For Industrial
  • Description
Model P/N: LP140WU1-SPA1
Diagonal Size: 14"
Panel Type: a-Si TFT-LCD, LCM
Pixel Number: 1920(RGB)×1200, 16:10, WUXGA
Pixel Format: RGB Vertical Stripe  LP140WU1-SPA1 14 inch 1920×1200 LCD Panel Display For Industrial

Parameter Detail
Model LP140WU1-SPA1 (LP140WU1 (SP)(A1), Product Code: LGD0689)
Brand LG Display
Panel Type a-Si TFT-LCD, LCM; IPS, Normally Black, Transmissive
Diagonal Size 14.0 Inches
Resolution 1920 (RGB) × 1200 (WUXGA), 16:10 Aspect Ratio, 161 PPI
Brightness 300 cd/m² (Typ.)
Contrast Ratio 1000:1 (Typ.) (Transmissive)
Response Time 30 ms (Typ.) (Tr+Td)
Viewing Angle 89/89/89/89 (Typ.) (CR≥10) (L/R/U/D)
Color Gamut 16.7M Colors
Surface Treatment Glare (0% Anti-glare/Hard Coating)
Signal Interface eDP (2 Lanes), eDP1.4, HBR1 (2.7G/lane); 30 Pins Connector
Power Supply 3.3V (Typ.)
Backlight WLED (Edge Light Type), 15K Hours Lifetime, with LED Driver
Operating Temperature 0 ~ 50 °C
Storage Temperature -20 ~ 60 °C
Active Area 301.594 (W) × 188.496 (H) mm
Outline Dimensions 306.59 (W) × 192.6 (H) × 3.7 (D) mm
Weight Approx. 1 kg
Touch Function Non-Touch

  • Ultrabook & Premium LaptopsThe LP140WU1-SPA1 is widely used in high-end ultrabooks and premium laptops, such as the LG Gram 14 series, thanks to its slim design, high resolution, and wide viewing angles. It delivers an immersive visual experience for content creation, video editing, and office work, supporting DCI-P3 color gamut for accurate color reproduction.
  • Industrial & Automotive DisplaysWith its wide operating temperature range (0–50°C) and robust construction, the panel is suitable for industrial control terminals, automotive infotainment systems, and medical devices. Its stable performance and anti-glare surface ensure clear visibility in harsh environments, such as manufacturing floors and vehicle cockpits.
  • Portable Monitors & All-in-One DevicesThe 14.0-inch size and lightweight design make it ideal for portable monitors, allowing users to extend their workspace on the go. It is also used in compact all-in-one PCs and thin-client terminals, delivering crisp, clear visuals for both personal and professional use.
  • Educational & Commercial DisplaysThe panel’s high resolution and wide viewing angles make it suitable for educational equipment, such as interactive whiteboards and student tablets. In commercial settings, it is used in point-of-sale (POS) systems, digital signage, and conference room displays, providing clear, legible content for extended periods.
