LG Display LP160WQ1-SPA1 16 inch 2560×1600 LCD Display Screen For Industrial

Name: LG Display LP160WQ1-SPA1 16 inch 2560×1600 LCD Display Screen For Industrial
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: LP160WQ1-SPA1
Price: 160 USD
Availability: InStock

SKU: LP160WQ1-SPA1

Model P/N: LP160WQ1-SPA1
Diagonal Size: 16"
Panel Type: Oxide TFT-LCD, LCM
Pixel Number: 2560(RGB)×1600, WQXGA, 16:10
Pixel Format: RGB Vertical Stripe

0.0 (0 Reviews)

0 Sold

~~$165.00~~ $160.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

LG Display LP160WQ1-SPA1 16 inch 2560×1600 LCD Display Screen For Industrial

Parameter	Specification	Unit
Model Number	LP160WQ1‑SPA1 (LGD0694)	–
Brand	LG Display	–
Display Size	16.0 (diagonal)	inch
Resolution	2560 (H) × 1600 (V) (WQXGA)	dots
Pixel Density	~188	PPI
Technology	Oxide TFT‑LCD, IPS (in‑plane switching)	–
Brightness (Typ.)	300	cd/m² (nits)
Contrast Ratio (Typ.)	1200:1	–
Viewing Angle	85/85/85/85 (L/R/U/D, CR≥10)	°
Response Time (Typ.)	30	ms
Interface	eDP 1.4, 40‑pin	–
Backlight	WLED, edge‑lit	–
Refresh Rate	60	Hz
Operating Voltage (VDD)	3.3	V
Operating Temperature	0 ~ +50	°C
Storage Temperature	-20 ~ +60	°C
Active Area (A.A.)	344.68 × 215.42	mm
Outline Dimensions	358.7 × 229.4 × 5.2 (max)	mm
Weight	≈350	g
Touch Screen	Non‑touch (optional capacitive)	–
Compliance	RoHS, REACH	–

Typical Applications

Premium Laptop PCs: Ultrabooks, creative workstations (e.g., LG Gram 16” series).
High‑End Portable Monitors: Lightweight external displays for travel and remote work.
Professional Displays: Photo/video editing, graphic design, and content creation.
Gaming & Entertainment: High‑color‑accuracy displays for media and casual gaming.
Industrial & Medical Displays: High‑resolution, reliable panels for non‑harsh industrial/medical equipment.
