Sharp LQ042T5DZ13A 4.2 inch 480×272 TFT-LCD Industrial Display Panel

SKU: LQ042T5DZ13A
Model: LQ042T5DZ13A
Brand: Sharp
Screen Size: 4.2 inches
Panel Type: a-Si TFT-LCD, VA, Transmissive
Resolution: 480 × 272 (WQVGA)
0.0 (0 Reviews)
0 Sold
$45.00 $43.00
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity:
-
+
  • Sharp LQ042T5DZ13A 4.2 inch 480×272 TFT-LCD Industrial Display Panel
  • Sharp LQ042T5DZ13A 4.2 inch 480×272 TFT-LCD Industrial Display Panel
  • Sharp LQ042T5DZ13A 4.2 inch 480×272 TFT-LCD Industrial Display Panel
  • Sharp LQ042T5DZ13A 4.2 inch 480×272 TFT-LCD Industrial Display Panel
  • Sharp LQ042T5DZ13A 4.2 inch 480×272 TFT-LCD Industrial Display Panel
  • Sharp LQ042T5DZ13A 4.2 inch 480×272 TFT-LCD Industrial Display Panel
1/1
  • Sharp LQ042T5DZ13A 4.2 inch 480×272 TFT-LCD Industrial Display Panel
  • Sharp LQ042T5DZ13A 4.2 inch 480×272 TFT-LCD Industrial Display Panel
  • Sharp LQ042T5DZ13A 4.2 inch 480×272 TFT-LCD Industrial Display Panel
  • Description
Sharp LQ042T5DZ13A 4.2 inch 480×272 TFT-LCD Industrial Display Panel
Parameter Details
Model LQ042T5DZ13A
Brand Sharp
Size 4.2"
Resolution 480×272 (WQVGA)
Panel Type a-Si TFT-LCD, VA, Transmissive
Brightness 500 cd/m² (Typ.)
Viewing Angle 85/85/85/85 (CR≥10)
Display Colors 262K (6-bit RGB)
Active Area 92.88 × 52.63 mm
Outline Dimension 102.5 × 69 × 12.3 mm
Backlight WLED, 10,000 hrs, with driver
Interface CMOS (1ch 6-bit), 50 pins
Operating Temp -30°C ~ +85°C
Storage Temp -40°C ~ +95°C
Touch Screen No
Weight Approx. 120g

Applications

  • Industrial HMI and control panels
  • Vehicle dashboards & construction machinery displays
  • Medical devices and testing instruments
  • Outdoor terminals and POS equipment
  • Portable industrial electronic devices
