LQ057AC213 5.7 Inch TFT LCD Screen 320×240 with 4-Wire Resistive Touch Industrial HMI Display Panel

SKU: LQ057AC213
Model Number: LQ057AC213
Display Size: 5.7 Inches
Panel Type: a-Si TFT-LCD, LCM (TN Technology)
Native Resolution: 320(RGB) × 240 QVGA, 4:3 Aspect Ratio
Dot Layout: RGB Vertical Stripe
0.0 (0 Reviews)
0 Sold
$65.00 $60.00
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity:
-
+
  • LQ057AC213 5.7 Inch TFT LCD Screen 320×240 with 4-Wire Resistive Touch Industrial HMI Display Panel
  • LQ057AC213 5.7 Inch TFT LCD Screen 320×240 with 4-Wire Resistive Touch Industrial HMI Display Panel
  • LQ057AC213 5.7 Inch TFT LCD Screen 320×240 with 4-Wire Resistive Touch Industrial HMI Display Panel
  • LQ057AC213 5.7 Inch TFT LCD Screen 320×240 with 4-Wire Resistive Touch Industrial HMI Display Panel
  • LQ057AC213 5.7 Inch TFT LCD Screen 320×240 with 4-Wire Resistive Touch Industrial HMI Display Panel
  • LQ057AC213 5.7 Inch TFT LCD Screen 320×240 with 4-Wire Resistive Touch Industrial HMI Display Panel
1/1
  • LQ057AC213 5.7 Inch TFT LCD Screen 320×240 with 4-Wire Resistive Touch Industrial HMI Display Panel
  • LQ057AC213 5.7 Inch TFT LCD Screen 320×240 with 4-Wire Resistive Touch Industrial HMI Display Panel
  • LQ057AC213 5.7 Inch TFT LCD Screen 320×240 with 4-Wire Resistive Touch Industrial HMI Display Panel
  • Description
LQ057AC213 5.7 Inch TFT LCD Screen 320×240 with 4-Wire Resistive Touch Industrial HMI Display Panel
Spec Item Detailed Parameter
Manufacturer CHI HSIN (Chilin)
Model Number LQ057AC213
Display Size 5.7 Inches
Panel Type a-Si TFT-LCD, LCM (TN Technology)
Native Resolution 320(RGB) × 240 QVGA, 4:3 Aspect Ratio
Dot Layout RGB Vertical Stripe
Brightness 300 cd/m² (Typical)
Backlight WLED, External Driver Required
Signal Interface Parallel TTL, 50 Pins FPC Connector
Touch Screen Built-in 4-Wire Resistive Touch Panel
Display Color 262K Colors
Operating Temperature -20 ℃ ~ +70 ℃
Storage Temperature -30 ℃ ~ +80 ℃
Application Industrial HMI, PLC Control Panel, Portable Test Instrument, Medical Equipment, Injection Molding Machine Display

Application

  • Industrial HMI Human Machine Interface touch control panels
  • PLC automation equipment & injection molding machine operation screens
  • Textile machinery, printing equipment embedded displays
  • Portable industrial testing & measuring instruments
  • Small medical diagnostic monitoring devices
  • Handheld industrial data collectors
  • CNC machine tool miniature operation terminals
  • Construction machinery vehicle-mounted control panels
