SHARP NEW 8.4 inch LCD Display Panel LQ084V1DG11 for Industrial
| Parameter |
Specification |
Notes |
| Model Number |
LQ084V1DG11 (Series) |
Sharp Corporation |
| Panel Type |
a-Si TFT-LCD |
Active Matrix |
| Screen Size |
8.4 inches |
Diagonal |
| Resolution |
640 × 480 pixels |
VGA Resolution |
| Aspect Ratio |
4:3 |
Standard Industrial Format |
| Active Area |
170.88 mm (W) × 128.16 mm (H) |
Viewable image area |
| Pixel Pitch |
0.267 mm (H) × 0.267 mm (V) |
Approx. |
| Overall Dimensions |
Approx. 221.0 mm × 152.4 mm × 12.5 mm |
Varies slightly by bezel/backlight unit |
| Color Depth |
262K colors (6-bit) / 16.7M (8-bit) |
Depends on interface wiring |
| Display Mode |
TN (Twisted Nematic) |
Transmissive, Normally White |
| Brightness |
300 ~ 350 cd/m² |
Typical value |
| Contrast Ratio |
250:1 to 400:1 |
Typical (CR ≥ 5) |
| Response Time |
15ms (Rise) / 30ms (Fall) |
Tr/Td typical |
| Viewing Angle |
60°/60°/45°/55° |
Left/Right/Up/Down (CR≥10) |
| Signal Interface |
TTL (50/60-pin) or LVDS |
Verify pinout for DG11 specifically; often TTL in this series. |
| Backlight Type |
CCFL (Cold Cathode Fluorescent Lamp) |
1 Lamp (Requires Inverter) |
| Power Supply Voltage |
3.3 V or 5.0 V (Logic) / High Voltage (Backlight) |
Logic: 3.3V ±0.3V or 5.0V ±0.5V |
| Operating Temp. |
-10°C to +60°C (Standard) / -20°C to +70°C (Wide) |
Depends on specific grade |
| Storage Temp. |
-30°C to +70°C |
- |
| Surface Treatment |
Anti-Glare (Matte), Hard Coating (3H) |
Reduces reflections, protects surface |
| Weight |
Approx. 350g - 450g |
With backlight unit |
Due to its compact 8.4-inch size, VGA resolution, and robust construction, the LQ084V1DG11 is widely used in:
-
Industrial Automation & HMI (Human Machine Interface):
- Control panels for CNC machines, injection molding controllers, and robotic arms.
- PLC (Programmable Logic Controller) interfaces and small-scale SCADA systems where a compact yet clear display is needed.
-
Medical Equipment:
- Patient monitoring systems (vital signs, ECG) in hospitals and ambulances.
- Portable diagnostic devices and infusion pumps requiring a stable, reliable screen.
-
Transportation & Automotive (Specialized):
- On-board computers for buses, trains, and fleet management vehicles.
- Dashboard displays for specialized heavy machinery (forklifts, excavators) and agricultural equipment.
-
Test & Measurement Instruments:
- Oscilloscopes, multimeters, and power supply testers that require a clear display for waveform visualization and data readouts.
-
Legacy System Upgrades & Maintenance:
- Direct replacement for aging 8.4-inch displays in older industrial equipment. Its compatibility with standard TTL controllers makes it a popular choice for retrofitting existing machinery without redesigning the entire control system.
