Condition: New and orignal , Grade A
Warranty : 1 year
Lead time : 1-3 working days
Shipping : DHL , FEDEX , EMS , UPS ..
| Brand | Sharp |
| Model P/N | LQ104V1DG11 |
| Diagonal Size | 10.4" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 640(RGB)×480, VGA 76PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 211.2(W)×158.4(H) mm |
| Bezel Opening | 215.2(W)×162.4(H) mm |
| Outline Size | 265(W)×195(H)×11.5(D) mm |
| Surface | Antiglare (Haze 28%), Hard coating (3H), Antireflection |
| Brightness | 350 cd/m² (Typ.) |
| Contrast Ratio | 300 : 1 (Typ.) (TM) |
| Viewing Angle | 70/70/40/70 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | 6 o'clock |
| Response Time | 20/40 (Typ.)(Tr/Td) |
| Display Colors | 262K |
| Lamp Type | 2 pcs CCFL, 50K hours, Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Weight | 695g (Typ.) |
| Signal Interface | Parallel RGB (1 ch, 6-bit), 31 pins Connector |
| Input Voltage | 5.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 55 °C; Storage Temp.: -25 ~ 70 °C |
This display panel is ideal for:
Industrial control panels and HMI (Human-Machine Interface)
Medical devices and diagnostic equipment
Measuring instruments and banking terminals
Industrial PCs and automation systems
Legacy system retrofits and equipment repairs
Test and measurement instruments
