Condition: New and orignal , Grade A
Warranty : 1 year
Lead time : 1-3 working days
Shipping : DHL , FEDEX , EMS , UPS ..
| Brand | Sharp |
| Model P/N | LQ121S1DG43 |
| Diagonal Size | 12.1" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 800(RGB)×600, SVGA 82PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 246(W)×184.5(H) mm |
| Bezel Opening | 249.0(W)×187.5(H) mm |
| Outline Size | 276(W)×209(H)×11(D) mm |
| Surface | Antiglare, Hard coating (3H) |
| Brightness | 370 cd/m² (Typ.) |
| Contrast Ratio | 450:1 (Typ.) (TM) |
| Viewing Angle | 70/70/50/60 (Typ.)(CR≥10) |
| Best View on | 6 o'clock |
| Response Time | 10/25 (Typ.)(Tr/Td) |
| Display Colors | 262K 50% NTSC |
| Lamp Type | 2 pcs CCFL, 50K hours, Without Driver |
| Touch Screen | Without |
| Panel Weight | 660g (Max.) |
| Application | Industrial HMI, CNC Controllers, Test Equipment, Legacy System Replacement |
| Signal Interface | Parallel RGB (1 ch, 6-bit), 41 pins Connector |
| Input Voltage | 3.3/5.0V (Typ.)(VCC) |
| Environment | Operating Temp.: -10 ~ 65 °C ; Storage Temp.: -30 ~ 70 °C |
Q: Do you conduct tests before shipment?
A: Yes, we strictly follow 100% pre-shipment testing procedures.Our testing process is standardized to ensure that every LCD panel sent to you is in compliance with specifications and is fully functional.
Q: What if the product doesn't work ?
A: Please test the product as soon as you receive it. If it does not work, take clear photos and videos of the issue and contact us immediately. We will then provide technical support or arrange a return or exchange.
