Sharp 15.6 inch 1920×1080 LQ156M1JW01 LCD Panel Screen For Industrial

Name: Sharp 15.6 inch 1920×1080 LQ156M1JW01 LCD Panel Screen For Industrial
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: LQ156M1JW01
Price: 83 USD
Availability: InStock

SKU: LQ156M1JW01

Model: LQ156M1JW01
Diagonal Size: 15.6 inch
Type: Oxide TFT-LCD, LCM
Pixel Number: 1920(RGB)×1080, 16:9, FHD
Pixel Structure: RGB Vertical Stripe

0.0 (0 Reviews)

0 Sold

~~$85.00~~ $83.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

Sharp 15.6 inch 1920×1080 LQ156M1JW01 LCD Panel Screen For Industrial

Parameter	Specification
Model	LQ156M1JW01
Brand	Sharp
Size	15.6 inch
Technology	Oxide TFT‑LCD, IPS, Normally Black, Transmissive
Resolution	1920 × 1080 (FHD, 16:9), 141 PPI
Brightness	300 cd/m² (Typ.)
Contrast Ratio	1000:1 (Typ.)
Viewing Angle	89°/89°/89°/89° (L/R/U/D, CR≥10)
Color Depth	16.7M colors (8‑bit)
Color Gamut	NTSC 71%, sRGB 100%
Backlight	WLED, lifespan ≥15,000 hrs
Interface	eDP 1.2 (2 lanes, 30 pins), HBR1 (2.7G/lane)
Refresh Rate	60 Hz
Operating Temp.	0 °C ~ +50 °C
Storage Temp.	−25 °C ~ +60 °C
Active Area	344.16 × 193.59 mm
Outline Dimensions	350.66 × 202.59 × 5.2 mm
Weight	Approx. 500 g
Surface	Matte (Antiglare)
Features	IPS full viewing angle, high color gamut, slim, light weight, RoHS compliant

Applications

Industrial HMI & Control Panels
Factory automation, PLC, CNC, industrial workstations.
Commercial Displays
Digital signage, kiosks, POS terminals, meeting room displays.
Medical Equipment
Patient monitors, diagnostic displays, portable medical devices.
Notebook & All‑in‑One PCs
High‑end laptops, industrial notebooks, AIO systems.
Embedded & Specialty Displays
Test instruments, gaming machines, educational devices.
