LRHBL6064A Graphic LCD Module for Industrial Equipment
| Parameter |
Specification |
Unit |
| Resolution |
64 × 64 (Square) |
dots |
| Display Mode |
FSTN, Positive, Transflective |
— |
| View Area |
31 × 31 |
mm |
| Active Area |
28.78 × 28.78 |
mm |
| Module Size |
35.6 × 40.6 × 4.0 (Typ.) |
mm |
| Dot Size / Pitch |
~0.45 × 0.45 / 0.5 × 0.5 |
mm |
| Controller |
UC1701 or equivalent |
— |
| Interface |
SPI / I²C (可选) |
— |
| Backlight |
LED (Yellow-Green / White) |
— |
| Supply Voltage |
3.3 (Typ., 3.0–3.6) |
V DC |
| Operating Current |
20–30 (without backlight) |
mA |
| Operating Temp |
-20 ~ +70 |
°C |
| Storage Temp |
-30 ~ +80 |
°C |
| Construction |
COG (Chip-on-Glass) |
— |
| Weight |
~25 |
g |
Typical application scenarios:
- Industrial handheld measuring instruments and portable detection devices
- Smart home control panels, intelligent sensor display terminals
- Medical portable health monitoring and small diagnostic equipment
- Automotive electronic instruments, tire pressure monitoring displays
- Access control system, doorbell intercom and security auxiliary display
- Wearable electronic devices and low-power consumer electronic products
- Small industrial control panels and automation auxiliary display modules
