LSUBL6176A 5.7 INCH LCD Display Screen For Industrial

Name: LSUBL6176A 5.7 INCH LCD Display Screen For Industrial
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: LSUBL6176A
Price: 108 USD
Availability: InStock

SKU: LSUBL6176A

Model: LSUBL6176A
Display Type: STN-LCD Module (Monochrome/Pseudo-color)
Diagonal Size: 5.7 inch
Resolution: 320 × 240 (QVGA)

0.0 (0 Reviews)

0 Sold

~~$110.00~~ $108.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

LSUBL6176A 5.7 INCH LCD Display Screen For Industrial

Parameter	Specification	Unit
Model	LSUBL6176A	—
Display Type	STN-LCD Module (Monochrome/Pseudo-color)	—
Diagonal Size	5.7	inch
Resolution	320 × 240 (QVGA)	pixel
Display Mode	STN, Positive, Transmissive	—
Brightness	210 (Typ.)	cd/m²
Contrast Ratio	4:1 (Typ.)	—
Viewing Angle	30/30/15/30 (L/R/U/D)	deg
Active Area	115.17 × 86.37	mm
Outline Dimension	165.5 × 112.3 × 8.5 (±0.5)	mm
Backlight	CCFL (Cold Cathode Fluorescent Lamp)	—
Interface	8-bit Parallel	—
Supply Voltage	5.0 (Typ.)	V DC
Operating Temperature	0 ~ +50	°C
Storage Temperature	-20 ~ +70	°C
Weight	Approx 165	g
Structure	COG + Metal Frame	—
