Toshiba LTM08C355A 8.4 Inch 800×600 a-Si TFT-LCD Panel Industrial Screen
| Spec Item |
Detailed Parameter |
| Manufacturer |
Toshiba Matsushita (Toshiba) |
| Model Number |
LTM08C355A |
| Screen Size |
8.4 inch |
| Panel Type |
a-Si TFT-LCD LCM, Normally White Transmissive |
| Native Resolution |
800(RGB) × 600, SVGA, 4:3 Aspect Ratio |
| Dot Layout |
RGB Vertical Stripe |
| Typical Brightness |
350 cd/m² |
| Contrast Ratio |
250:1 (Typical) |
| Viewing Angle (CR≥10) |
50°/50°/40°/50° (H/V) |
| Backlight |
Dual CCFL Lamps, 50,000 Hours Lifespan, No Built-in Driver |
| Signal Interface |
Single Channel 6-bit CMOS TTL, 30 Pin Connector |
| Refresh Rate |
60Hz |
| Touchscreen |
Without Touch Function |
| Net Weight |
~0.5 Kgs |
| Operating Temperature |
0 ~ 50℃ |
| Storage Temperature |
-20 ~ 60℃ |
| Application Grade |
Industrial, Medical, Equipment Replacement |
Application
1. Industrial Automation & CNC Equipment
CNC machine tool control panels, injection molding machine HMI displays, PLC industrial touch all-in-one replacement screens, production line monitoring terminals, mechanical equipment operation controllers.
2. Medical Diagnostic Devices
Patient monitoring equipment, clinical testing instruments, portable medical diagnostic terminals, hospital ward control display screens.
3. Legacy Industrial Terminals
Old factory access control displays, laboratory inspection instruments, industrial testing measuring equipment, textile machinery control panels.
4. Equipment Repair & Refurbishment
Direct replacement screen for broken original Toshiba 8.4" industrial monitors, machinery maintenance spare parts, second-hand equipment renovation projects.
