Mitsubishi MAA121DSP01 12.1 inch 800×600 LCD Panel Display For Industrial

SKU: MAA121DSP01
Model P/N: MAA121DSP01
Diagonal Size: 12.1"
Panel Type: a-Si TFT-LCD, LCM
Pixel Number: 800(RGB)×600, 4:3, SVGA
Pixel Format: RGB Vertical Stripe
0.0 (0 Reviews)
0 Sold
$85.00 $80.00
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity:
-
+
  • Mitsubishi MAA121DSP01 12.1 inch 800×600 LCD Panel Display For Industrial
  • Mitsubishi MAA121DSP01 12.1 inch 800×600 LCD Panel Display For Industrial
  • Mitsubishi MAA121DSP01 12.1 inch 800×600 LCD Panel Display For Industrial
  • Mitsubishi MAA121DSP01 12.1 inch 800×600 LCD Panel Display For Industrial
  • Mitsubishi MAA121DSP01 12.1 inch 800×600 LCD Panel Display For Industrial
  • Mitsubishi MAA121DSP01 12.1 inch 800×600 LCD Panel Display For Industrial
1/1
  • Mitsubishi MAA121DSP01 12.1 inch 800×600 LCD Panel Display For Industrial
  • Mitsubishi MAA121DSP01 12.1 inch 800×600 LCD Panel Display For Industrial
  • Mitsubishi MAA121DSP01 12.1 inch 800×600 LCD Panel Display For Industrial
  • Description
Mitsubishi MAA121DSP01 12.1 inch 800×600 LCD Panel Display For Industrial
Parameter Specification
Manufacturer Mitsubishi
Model MAA121DSP01
Panel Type a-Si TFT-LCD, LCM
Diagonal Size 12.1 inches
Resolution 800 × 600 (SVGA)
Pixel Format RGB Vertical Stripe
Active Area 246.0 × 184.5 mm
Outline Dimension 280.0 × 210.0 × 12.5 mm
Brightness 450 cd/m² (Typ.)
Contrast Ratio 600:1 (Typ.)
Viewing Angle 65°/65°/45°/75° (L/R/U/D, CR≥10)
Response Time 20/30 ms (Tr/Td, Typ.)
Display Mode TN, Normally White, Transmissive
Surface Treatment Antiglare, Hard coating (3H)
Backlight CCFL (2 lamps, Edge-lit)
Interface LVDS (1 ch, 6/8-bit), 20 pins
Supply Voltage 3.3 V DC (Typ.)
Operating Temperature -20°C ~ +70°C
Storage Temperature -20°C ~ +80°C
Color Depth 262K colors (6-bit)
Refresh Rate 60 Hz
Weight Approx. 2.0 kg
Status Discontinued
