| Display Size |
5.7 inches |
7.5 inches |
| Resolution |
320 × 240 (QVGA) |
640 × 480 (VGA) |
| Display Type |
Monochrome STN LCD (4-level grayscale) |
Color TFT LCD (65,536 colors) |
| Touchscreen |
Resistive (4-wire) |
Resistive (4-wire) |
| Backlight |
CCFL (Cold Cathode Fluorescent Lamp) |
LED |
| Memory |
～512 KB SRAM + 1 MB Flash |
～2 MB SRAM + 4 MB Flash |
| Communication |
RS-232C, RS-422 (for PLC) |
RS-232C, RS-422/485, Ethernet (10/100 Mbps) |
| Native Protocol |
MELSEC ASCII / FX Series |
MELSEC MC Protocol (Q/L/FX) |
| Other Protocols |
Limited Modbus RTU |
Modbus RTU/TCP, CC-Link IE Field Basic |
| Programming Software |
GT Designer2 (legacy) |
GT Designer3 (current, free) |
| Power Supply |
24 VDC ±10% |
24 VDC ±10% |
| Protection Rating |
IP65F (front) |
IP65F (front) |
| Status |
Discontinued (～2012) |
Still available (as of 2026) |
