New Touch Screen N010-0554-X255-01 3D
1. Core Sensor & Imaging Specifications
Parameter Specification Notes
Brand Teledyne DALSA
Series Genie Nano Series
Model Number N010-0554-X255-01
Technology 3D Machine Vision Camera Laser triangulation-based 3D profiling
Sensor Type High-speed CMOS image sensor Proprietary Teledyne DALSA sensor
Resolution (2D Mode) High resolution (specific pixel count TBC) Typically in megapixel range
3D Profile Points Up to 2048 points per profile High-density 3D data capture
Scan Rate Up to 10,000+ profiles/second High-speed inline inspection capable
Interface GigE Vision Standard Gigabit Ethernet interface
2. 3D Performance Specifications
Parameter Specification Notes
Measurement Principle Laser triangulation Projects laser line for height profiling
Z-Axis Resolution High precision (micrometer level) Varies with field of view and working distance
X-Axis Resolution Configurable based on optics Depends on lens selection
Field of View (FOV) Configurable Interchangeable lens options available
Working Distance Configurable Application-dependent
Laser Class Class 2 or Class 3R (depending on configuration) Safe for industrial use with proper precautions
3. Physical & Environmental Specifications
Parameter Specification Notes
Dimensions (L×W×H) Compact industrial form factor Approx. 45 × 45 × 60 mm (typical Genie Nano size)
Weight Lightweight (approx. 100-150g) Suitable for robotic mounting
Enclosure Rating IP30 (requires housing for harsh environments) Protected against solid objects
Operating Temperature 0°C to 50°C Industrial temperature range
Storage Temperature -20°C to 70°C
Humidity 20% to 80% RH (non-condensing)
Power Consumption < 5W via Power over Ethernet (PoE) Single-cable operation
4. Interface & Connectivity
Parameter Specification Notes
Data Interface GigE Vision Industry standard for machine vision
Power Power over Ethernet (PoE) IEEE 802.3af compliant
Protocol Support GenICam compliant Standardized programming interface
Connector RJ45 with locking screws Industrial Ethernet connector
Trigger Input Opto-isolated trigger input For precise synchronization
Strobe Output Programmable strobe output For external lighting control
5. Software & Development Support
Feature Description
SDK Support Teledyne DALSA Sapera™ LT SDK Comprehensive development toolkit
3D Software Sapera Processing with 3D modules Advanced 3D measurement libraries
Compatibility Windows/Linux support Multiple OS support
API Support C++, C#, .NET APIs Flexible programming options
Third-Party Integration Compatible with Halcon, Cognex, OpenCV Popular vision library support
6. Key Features & Benefits
Feature Benefit
High-Speed 3D Profiling Enables real-time inline inspection at production speeds
Compact Form Factor Easy integration into space-constrained machines
GigE Vision Standard Simple integration with existing vision systems
Power over Ethernet Reduces cabling complexity
GenICam Compliance Standardized programming interface reduces development time
Teledyne DALSA Sensor Technology Superior image quality and reliability
Industrial Design Robust for factory floor deployment
