LM238WF2-SSK2 | LG Display 23.8” FHD IPS TFT-LCD Panel
LM238WF2-SSK2 is a 23.8-inch FHD (1920×1080) IPS a-Si TFT-LCD panel by LG Display, designed for industrial monitors, all-in-one PCs, and professional display applications. It features 250 cd/m² brightness, 1000:1 contrast, 89° ultra-wide viewing angles, and 16.7M colors for consistent visual performance.
| Parameter Item |
Specification Details |
| Part Number |
LM238WF2-SSK2 |
| Manufacturer |
LG Display |
| Display Size |
23.8 inch, landscape |
| Native Resolution |
1920(RGB) × 1080 pixels (FHD, 92PPI) |
| Display Technology |
a-Si TFT-LCD, IPS, normally black, transmissive |
| Active Area |
527.04 mm (W) × 296.46 mm (H) |
| Outline Dimension |
542.0 mm (W) × 316.0 mm (H) × 14.2 mm (D) |
| Brightness |
250 cd/m² (Typ.) |
| Contrast Ratio |
1000:1 (Typ.) |
| Viewing Angle |
89°/89°/89°/89° (L/R/U/D, CR≥10) |
| Response Time |
14 ms (Typ., G to G) |
| Display Colors |
16.7M (24-bit RGB, 69% NTSC) |
| Backlight |
15S4P WLED, 30,000 hours lifespan, no onboard driver |
| Interface |
Dual-channel LVDS (2 ch, 8-bit), 30 pins connector |
| Supply Voltage |
5.0 V (Typ.) |
| Operating Temperature |
0°C ~ +50°C |
| Storage Temperature |
–20°C ~ +60°C |
| Surface Treatment |
Matte (anti-glare) |
| Weight |
Approx. 1.2 kg |
| Certifications |
RoHS compliant |
