TSD-ST157-M-TYD
TSD-ST157-M-TYD is a 15.7-inch industrial TFT-LCD display module with touch, featuring 1280×1024 SXGA resolution, high-brightness LED backlight, and industrial-grade touch screen. Designed for rugged environments, it delivers stable performance, wide viewing angles, and long-term reliability for industrial HMI and embedded systems.
| Parameter |
Details |
| Model |
TSD-ST157-M-TYD |
| Display Size |
15.7 inches (diagonal) |
| Resolution |
1280 × 1024 pixels (SXGA) |
| Panel Technology |
a-Si TFT-LCD (TN, Normally White) |
| Active Area (W×H) |
320.0 × 256.0 mm |
| Outline Dimensions |
350 × 286 × 12.5 mm |
| Brightness |
450 cd/m² (typical) |
| Contrast Ratio |
800:1 (typical) |
| Display Colors |
16.7M (8-bit RGB) |
| Viewing Angles |
85°/85°/80°/80° (L/R/U/D, CR≥10) |
| Backlight |
LED (lifetime: 50,000 hours) |
| Touch Screen |
Resistive touch (4-wire, industrial grade) |
| Interface |
LVDS (2-channel, 8-bit) |
| Operating Voltage |
12 V (typical) |
| Operating Temperature |
−20°C ~ +70°C |
| Storage Temperature |
−30°C ~ +80°C |
| Weight |
~1.2 kg |
| Certifications |
RoHS compliant |
| Status |
Active (industrial standard) |
