NLT NL128102AC29-17G 19 Inch TFT LCD Screen 1280×1024 Industrial Display Panel

Name: NLT NL128102AC29-17G 19 Inch TFT LCD Screen 1280×1024 Industrial Display Panel
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: NL128102AC29-17G
Price: 200 USD
Availability: InStock

SKU: NL128102AC29-17G

Model No.: NL128102AC29-17G
Display Size: 19.0 Inches
Panel Type: a-Si TFT-LCD, LCM, SFT Wide View Technology
Native Resolution: 1280(RGB) × 1024 SXGA, 5:4 Aspect Ratio
Dot Layout: RGB Vertical Stripe

0.0 (0 Reviews)

0 Sold

~~$210.00~~ $200.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

NLT NL128102AC29-17G 19 Inch TFT LCD Screen 1280×1024 Industrial Display Panel

Spec Item	Detailed Parameter
Manufacturer	NLT (Former NEC LCD)
Model No.	NL128102AC29-17G
Display Size	19.0 Inches
Panel Type	a-Si TFT-LCD, LCM, SFT Wide View Technology
Native Resolution	1280(RGB) × 1024 SXGA, 5:4 Aspect Ratio
Dot Layout	RGB Vertical Stripe
Display Mode	Normally Black, Transmissive
Brightness	800 cd/m² (Typ.) Sunlight Readable
Contrast Ratio	1000:1 (Typ.)
Viewing Angle	88°/88°/88°/88° (CR≥10, All Symmetric)
Color Performance	16.7M Full Colors, 72% NTSC Color Gamut
Refresh Frequency	60Hz
Signal Interface	2 Channel 8-bit LVDS Connector
Touch Screen	Without Touch Digitizer
Display Area	376.32(W) × 301.056(H) mm
Overall Outline Size	396(W) × 324(H) × 18.5(D) mm
Net Weight	2.10kg (Typ.) / 2.31kg (Max.)
Surface Treatment	Clear Hard Coating
Operating Temperature	-20 ℃ ~ +70 ℃
Storage Temperature	-30 ℃ ~ +80 ℃
