Condition: New and orignal , Grade A
Warranty : 1 year
Lead time : 1-3 working days
Shipping : DHL , FEDEX , EMS , UPS ..
| Brand | NEC |
| Model P/N | NL6448BC33-63D |
| Diagonal Size | 10.4" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 640(RGB)×480, VGA, 76PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 211.2(W)×158.4(H) mm |
| Bezel Opening | 215.4(W)×161.8(H) mm |
| Outline Size | 243(W)×185.1(H)×11(D) mm |
| Surface | Antiglare, Hard coating (3H) |
| Brightness | 450 cd/m² (Typ.) |
| Contrast Ratio | 600 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/60 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | 6 o'clock |
| Response Time | 6/19 (Typ.)(Tr/Td) ms |
| Display Colors | 262K / 16.7M, 40% NTSC |
| Lamp Type | 2 pcs CCFL, 50K hours, Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 475g / 500g (Typ./Max.) |
| Signal Interface | LVDS (1 ch, 6/8-bit), 20 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -20 ~ 70 °C; Storage Temp.: -30 ~ 80 °C; Vibration Level: 2.0G (19.6 m/s²) |
This industrial-grade display panel is ideally suited for :
Factory Automation (FA) Equipment: Control panels for manufacturing systems
Measurement Instruments: Test and measurement devices requiring precise readouts
Industrial Human-Machine Interfaces (HMIs): Operator terminals for machinery control
Medical Equipment: Monitoring devices (not specifically designed for life support)
Communications Equipment: Networking hardware displays
Textile Machinery: Replacement for aging displays in industrial looms
Injection Molding Machines: Control panel upgrades
Printing Presses: Display systems for Heidelberg, Roland, Komori equipment
