NL6448BC33-70K 10.4" 640×480 NEC a-Si TFT-LCD Panel Display Screen for Industrial
Product Description:
The NL6448BC33-70K is a robust 10.4-inch TFT-LCD module, part of the long-lifecycle NEC industrial display portfolio. Designed for mission-critical environments, it features a standard VGA resolution of 640x480 pixels using reliable a-Si TFT technology. The "-70" designation confirms it is equipped with a White LED (WLED) backlight, offering superior energy efficiency, mercury-free compliance, and an extended operational life exceeding 70,000 hours compared to legacy CCFL units. The "K" suffix often specifies a unique connector interface or cable assembly tailored for specific OEM integrations, ensuring secure connectivity in high-vibration settings. This module operates reliably across a wide temperature range (typically -30°C to +80°C), making it ideal for factory automation, medical devices, and transportation systems. With a typical brightness of 450 cd/m² and a sturdy metal frame, the NL6448BC33-70K delivers consistent visual performance in harsh conditions where consumer displays would fail.
| Parameter |
Specification Details |
| Model Number |
NL6448BC33-70K |
| Manufacturer |
NEC |
| Display Type |
a-Si TFT-LCD |
| Screen Size |
10.4 inches |
| Resolution |
640 (RGB) × 480 [VGA] |
| Active Area |
211.2 × 158.4 mm |
| Outline Dimensions |
243 × 185.1 × 11 (H×V×D) mm |
| Brightness |
450 cd/m² (Typical) |
| Contrast Ratio |
900 : 1 (Typ.) (TM) |
| Viewing Angle |
80/80/80/80 (Typ.)(CR≥10) |
| Color Depth |
262K colors (6-bit) |
| Interface Type |
CMOS (1 ch, 6-bit) , 31 pins Connector |
| Backlight Type |
WLED |
| Operating Temperature |
-30 ~ 80 °C |
| Storage Temperature |
-30 ~ 80 °C |
| Touch Panel |
No Touch (Open Frame Module) |
| Special Feature |
"K" Variant: Specific connector/cable config for rugged integration |
| Reliability |
High shock/vibration resistance, RoHS Compliant |
NEC
Specific Applications:
The NL6448BC33-70K is widely deployed in sectors that require proven reliability and long-term supply stability:
-
Industrial Automation & Control:
- HMI Panels: Human-Machine Interfaces for PLCs, SCADA systems, and CNC machine tools where vibration resistance is critical.
- Factory Floor Monitors: Displays for assembly lines, robotic control stations, and quality inspection systems operating in dusty or hot environments.
- Legacy Upgrades: Direct replacement for aging CCFL-backlit screens in older industrial equipment, providing modern LED reliability without redesigning the enclosure.
-
Medical Equipment:
- Patient Monitoring Systems: Vital signs monitors in ICUs, ERs, and ambulances requiring flicker-free LED backlighting and stable performance.
- Diagnostic Devices: Ultrasound consoles, infusion pumps, and laboratory analyzers where long-term availability of the display model is crucial for device certification.
- Portable Medical Carts: Battery-operated diagnostic tools benefiting from the lower power consumption of the LED backlight.
-
Transportation & Marine:
- Railway Systems: Driver display units (DDU) and passenger information displays in trains, capable of withstanding extreme temperature cycles and constant vibration.
- Marine Navigation: Engine monitoring screens and chart plotters on ships, resistant to humidity and salt spray environments (when properly sealed in the end product).
- Aviation Ground Support: Maintenance diagnostic terminals and ground vehicle instrumentation.
-
Test & Measurement:
- Benchtop Instruments: Oscilloscopes, spectrum analyzers, and power supplies used in R&D and manufacturing testing.
- Portable Testers: Handheld field service devices for telecommunications and utilities.
This display module represents a cornerstone of industrial embedded design, offering a balance of legacy compatibility (VGA/TTL) and modern efficiency (LED), ensuring systems remain operational for decades.
