NEC/NLT10.4 inch LCD Display Panel NL8060AC31-17 for Industrial NEW
| Parameter |
Specification |
| Model Number |
NL8060AC31-17 |
| Manufacturer |
NEC Display Solutions |
| Panel Type |
a-Si TFT Active Matrix LCD |
| Diagonal Size |
12.1 inches |
| Resolution |
800 (RGB) × 600 pixels (SVGA) |
| Pixel Arrangement |
RGB Vertical Stripe |
| Display Colors |
262K (6-bit) |
| Active Area (H×V) |
246.0 × 184.5 mm |
| Outline Dimensions (W×H×D) |
Approx. 280.0 × 210.0 × 13.7 mm |
| Interface Type |
TTL (Parallel RGB, 18-bit or 24-bit depending on config) |
| Input Voltage |
5.0V (Typical for Logic and Backlight Inverter) |
| Brightness |
350 cd/m² (Typical) |
| Contrast Ratio |
350:1 (Typical) |
| Response Time |
15 ms (Typical, Tr+Td) |
| Viewing Angle |
55°/55°/40°/50° (Left/Right/Up/Down, CR≥10) |
| Backlight Type |
CCFL (Cold Cathode Fluorescent Lamp), 2 lamps |
| Surface Treatment |
Anti-Glare (Matte), Hard Coating |
| Operating Temperature |
-20°C to +70°C (Standard); Some AC variants support -30°C to +80°C |
| Storage Temperature |
-30°C to +80°C |
| Weight |
Approx. 750 g |
| Power Consumption |
Approx. 8.3 W (Typical with backlight on) |
| Mounting |
Standard screw holes on metal bezel |
NEC/NLT
The NL8060AC31-17 is a high-reliability 12.1-inch a-Si TFT-LCD module manufactured by NEC Display Solutions. Designed specifically for industrial and embedded systems, this panel offers an SVGA resolution (800×600) and supports 262,144 colors (6-bit).
A key feature of the "AC" series (as opposed to the "BC" series) is its enhanced robustness, often including a wider operating temperature range and superior mechanical stability. The NL8060AC31-17 typically features a TTL (Parallel RGB) interface, making it easy to integrate with standard industrial controllers and single-board computers without complex timing converters. It utilizes a CCFL backlight system (common for this generation) to provide uniform illumination with a typical brightness of 350 cd/m², ensuring readability in various lighting conditions. Its rugged construction and long lifecycle support make it a preferred choice for mission-critical applications in automation, medical, and transportation sectors.
The NL8060AC31-17 is widely used in the following sectors:
-
Industrial Automation & Control Systems:
- HMI (Human-Machine Interfaces): Used as the display unit for PLCs and SCADA systems in factories.
- CNC Machines: Display panels for numerical control systems in lathes, milling machines, and laser cutters.
- Robotics Controllers: Teaching pendants and status monitors for industrial robots.
-
Medical Equipment:
- Patient Monitors: Bedside monitoring systems requiring stable, continuous operation.
- Diagnostic Imaging: Older generation ultrasound or X-ray console displays where SVGA resolution is sufficient.
- Infusion Pumps & Analyzers: Embedded displays in laboratory and clinical devices.
-
Transportation & Marine:
- Railway Control Panels: Driver consoles and passenger information systems (due to vibration resistance).
- Marine Navigation: Chart plotters and engine room monitoring systems.
- Specialty Vehicles: Displays in agricultural machinery, construction equipment, and military vehicles.
-
Point of Sale (POS) & Banking:
- ATM Machines: Customer interface screens.
- Industrial POS Terminals: Ruggedized checkout systems for harsh retail environments.
-
Test & Measurement Instruments:
- Oscilloscopes, signal generators, and power analyzers requiring a clear, readable interface in lab or field settings.
