| Parameter | Value |
|---|---|
| Brand | NEC |
| Model P/N | NL8060BC26-27 |
| Diagonal Size | 10.4" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 800(RGB)×600, SVGA, 96 PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 211.2(W)×158.4(H) mm |
| Bezel Opening | 215.4(W)×161.8(H) mm |
| Outline Size | 243.0(W)×185.1(H)×11.0(D) mm |
| Surface | Clear, Hard coating (3H) |
| Brightness | 400 cd/m² (Typ.) |
| Contrast Ratio | 700:1 (Typ.) (TM) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) |
| Display Mode | SA-SFT, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 25/25 (Typ.)(Tr/Td) |
| Display Colors | 262K, 40% NTSC |
| Lamp Type | 2 pcs CCFL, 50,000 hours, Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 475/500g (Typ./Max.) |
| Signal Interface | CMOS (1 ch, 6-bit), 41 pins Connector |
| Input Voltage | 3.3/5.0V (Typ.)(VCC) |
| Environment | Operating Temp.: -10 ~ 70 °C; Storage Temp.: -20 ~ 80 °C; Vibration Level: 2.0G (19.6 m/s²) |
The NL8060BC26-27 is ideally suited for:
Industrial control systems and HMIs (Human-Machine Interfaces)
Process controllers and monitoring systems
CNC machine tools and injection molding equipment
Medical monitoring equipment
Banking terminals and ATMs
Test and measurement instruments
Factory automation equipment
Military and industrial equipment requiring durable display solutions.
FAQ
Q: How long will I receive my goods ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX
Q:Can you give me a discount if I need a large quantity of ?
A:Of course!If you make a large order, we will give you a discount.
Q:Can I pay my order via credit card ?
A:Yes!you can use your credit card through your Paypal account.
Q: May I ask what kind of packaging you use?
A: We use anti-static packaging and shock-resistant packaging.Anti-static packaging: Ensure that the packaging materials used comply with ESD standards, including anti-static bags and foam.Shock-resistant packaging: Use custom foam and sturdy outer boxes to ensure that they can pass through regular transportation tests (such as dropping and vibration).So the goods arrive at your hands in perfect condition.
Q: Do you conduct tests before shipment?
A: Yes, we strictly follow 100% pre-shipment testing procedures.Our testing process is standardized to ensure that every LCD panel sent to you is in compliance with specifications and is fully functional.
