| Brand | NEC |
| Model P/N | NL8060BC31-17 |
| Diagonal Size | 12.1" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 800(RGB)×600, SVGA 82PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 246(W)×184.5(H) mm |
| Bezel Opening | 249.0(W)×187.5(H) mm |
| Outline Dim. | 280(H)×210(V)×13.7(D) mm |
| Luminance | 350 cd/m² (Typ.) |
| Contrast Ratio | 350:1 (Typ.) (TM) |
| View Direction | 6 o'clock |
| Response Time | 15/55 (Typ.)(Tr/Td) |
| Viewing Angle | 55/55/40/50 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 262K 43% NTSC |
| Light Source | CCFL [2 pcs], W/O Driver |
| Weight | 750/780g (Typ./Max.) |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | CMOS (1 ch, 6-bit), 41 pins Connector |
| Power Supply | 3.3/5.0V (Typ.)(VCC) |
| Environment | Operating Temperature: 0 ~ 50 °C; Storage Temperature: -20 ~ 60 °C; Vibration Level: 2.0G (19.6 m/s²) |
Industrial Control Panels and HMIs
Factory Automation Equipment
Process Control Monitors
Test and Measurement Instruments
Medical Monitoring Systems
CNC Machine Displays
Legacy System Upgrades and Retrofits
