| Parameter | Value |
|---|---|
| Brand | NEC |
| Model P/N | NL8060BC31-32 |
| Diagonal Size | 12.1" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 800(RGB)×600, SVGA, 82 PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 246.0(W)×184.5(H) mm |
| Bezel Opening | 249.0(W)×187.5(H) mm |
| Outline Size | 280.0(W)×210.0(H)×13.7(D) mm |
| Surface | Clear, Hard coating (2H), Antireflection |
| Brightness | 400 cd/m² (Typ.) |
| Contrast Ratio | 600:1 (Typ.) (TM) |
| Viewing Angle | 70/70/45/55 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | 6 o'clock |
| Response Time | 8/25 (Typ.)(Tr/Td) |
| Display Colors | 262K, 40% NTSC |
| Lamp Type | 2 pcs CCFL, Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Weight | 745/775g (Typ./Max.) |
| Application | - (Icon reference) |
| Signal Interface | CMOS (1 ch, 6-bit), 41 pins Connector |
| Input Voltage | 3.3/5.0V (Typ.)(VCC) |
| Environment | Operating Temp.: -10 ~ 70 °C; Storage Temp.: -20 ~ 80 °C; Vibration Level: 2.0G (19.6 m/s²) |
The NL8060BC31-32 is ideally suited for:
Industrial control systems and HMIs (Human-Machine Interfaces)
Factory automation and process controllers
CNC machine tools and injection molding equipment
Medical monitoring equipment
ATMs (Automated Teller Machines) and banking terminals
Measuring devices and test instruments
Vending machines and kiosk systems
Industrial devices subject to use in bright sunlight .
