NEC/NLT 12.1 inch LCD Display Panel NL8060BC31-41 for Industrial NEW
| Parameter |
Specification |
| Model Number |
NL8060BC31-41 (Variants: -41D, -41E) |
| Manufacturer |
NEC Display Solutions |
| Panel Type |
a-Si TFT Active Matrix LCD |
| Diagonal Size |
12.1 inches |
| Resolution |
800 (RGB) × 600 pixels (SVGA) |
| Pixel Arrangement |
RGB Vertical Stripe |
| Display Colors |
262K (6-bit) / Some variants support 16.2M via dithering |
| Active Area (H×V) |
246.0 × 184.5 mm |
| Outline Dimensions (H×V×D) |
Approx. 280.0 × 210.0 × 9.6 mm (varies slightly by suffix) |
| Interface Type |
TTL (Parallel RGB) |
| Input Voltage |
3.3V / 5.0V (Logic & Backlight depend on config) |
| Brightness |
400 cd/m² (Typical) |
| Contrast Ratio |
600:1 (Typical) |
| Response Time |
6ms (Rise) / 19ms (Fall) Typical |
| Viewing Angle |
80°/80°/80°/60° (Left/Right/Up/Down, CR≥10) |
| Backlight Type |
CCFL (2 lamps) or WLED (depending on specific sub-model) |
| Surface Treatment |
Anti-Glare (Matte), Hard Coating (3H) |
| Operating Temperature |
-20°C to +70°C (Standard Industrial); Some versions -30°C to +80°C |
| Storage Temperature |
-30°C to +80°C |
| Weight |
Approx. 740g - 800g |
| Mounting |
Standard screw holes on bezel |
NEC/NLT
The NL8060BC31-41 is a robust 12.1-inch a-Si TFT-LCD module manufactured by NEC Display Solutions (now part of Sharp/NEC). It is designed primarily for industrial and embedded applications, offering high reliability, wide temperature operation, and a long lifecycle. The display features an SVGA resolution (800×600) with support for 262,144 colors (6-bit). It typically utilizes a TTL (Transistor-Transistor Logic) interface for direct connection to industrial controllers and is backlit by CCFL (Cold Cathode Fluorescent Lamp) or LED depending on the specific sub-version, ensuring high brightness suitable for environments with ambient light.
The NL8060BC31-41 is widely used in the following sectors:
-
Industrial Automation & Control Systems:
- HMI (Human-Machine Interfaces): Used as the display unit for PLCs and SCADA systems in factories.
- CNC Machines: Display panels for numerical control systems in lathes, milling machines, and laser cutters.
- Robotics Controllers: Teaching pendants and status monitors for industrial robots.
-
Medical Equipment:
- Patient Monitors: Bedside monitoring systems requiring stable, continuous operation.
- Diagnostic Imaging: Older generation ultrasound or X-ray console displays where SVGA resolution is sufficient.
- Infusion Pumps & Analyzers: Embedded displays in laboratory and clinical devices.
-
Transportation & Marine:
- Railway Control Panels: Driver consoles and passenger information systems (due to vibration resistance).
- Marine Navigation: Chart plotters and engine room monitoring systems.
- Specialty Vehicles: Displays in agricultural machinery, construction equipment, and military vehicles.
-
Point of Sale (POS) & Banking:
- ATM Machines: Customer interface screens.
- Industrial POS Terminals: Ruggedized checkout systems for harsh retail environments.
-
Test & Measurement Instruments:
- Oscilloscopes, signal generators, and power analyzers requiring a clear, readable interface in lab or field settings.
