NT31C-ST143-EV3 | Omron 5.7" Resistive Touch HMI Panel
NT31C-ST143-EV3 is original Omron industrial 5.7-inch color STN resistive touch HMI, export EV3 global version equipped with analog resistive touch overlay, 320×240 resolution 8-color STN LCD, multi-communication serial ports and front IP65 waterproof & dustproof rating. It supports gloved hand operation, stable DC24V power input and seamless connection with Omron series PLCs, widely used as replacement spare touch screen for legacy automation equipment after original production discontinuation。
| Parameter Item |
Detailed Spec |
| Part No. |
NT31C-ST143-EV3 (EV3=Global Export Version) |
| Brand |
Omron Japan |
| Screen Size |
5.7 inch |
| Display Type |
Color STN LCD, 8 display colors |
| Native Resolution |
320(H) × 240(V) pixels |
| Active Display Area |
118.2mm(W) × 89.4mm(H) |
| Touch Type |
4-Wire Analog Resistive Touchscreen |
| Touch Feature |
Support glove/oily hand tapping, single-point lifespan＞25 million touches |
| Front Panel Grade |
IP65 / NEMA4 (dustproof & splash-proof), rear IP20 |
| Power Supply |
DC24V, allowable range DC20.4~26.4V |
| Max Power Consumption |
≤15W |
| Communication Interface |
Host Link / NT Link, RS232C, RS422A |
| Mounting Method |
Embedded cabinet panel mount |
| Net Weight |
0.41kg |
| Operating Temp |
0℃ ~ +50℃ |
| Storage Temp |
-20℃ ~ +60℃ |
| Operating Humidity |
35%~85%RH (non-condensing) |
| Certification |
CE, UL, RoHS compliant |
| Production Status |
Discontinued original production, aftermarket replacement spare part availa |
