The OPTREX T-51512D121J-FW-A-AB is a 12.1-inch color a-Si TFT-LCD (Thin Film Transistor Liquid Crystal Display) module designed for industrial and commercial applications. Manufactured by OPTREX Corporation, this module integrates an LCD panel, driver ICs, control circuitry, and a CCFL backlight unit into a compact, robust package .
This SVGA-resolution display delivers clear, reliable performance for applications requiring stable, long-life operation in demanding environments.
| Parameter |
Specification |
| Brand |
OPTREX |
| Model |
T-51512D121J-FW-A-AB |
| Diagonal Size |
12.1 inch |
| Type |
a-Si TFT-LCD, LCM |
| Pixel Number |
800(RGB)×600, SVGA, 4:3 |
| Pixel Format |
RGB Vertical Stripe |
| Active Area |
246(H)×184.5(V) mm |
| Physical Size |
280(H)×210(V)×12.5(D) mm |
| Mass |
720g (Typ.) |
| Surface Coating |
Antiglare, Hard coating (3H) |
| Luminance |
400 cd/m² (Typ.) |
| Contrast Ratio |
500:1 (Typ.) (TM) |
| View Direction |
6 o'clock |
| Response Time |
10/30 (Typ.)(Tr/Td) ms |
| Viewing Angle |
65/65/45/75 (Typ.)(CR≥10) |
| Operating Mode |
TN, Normally White, Transmissive |
| Support Color |
262K, 40% NTSC |
| Light Source |
2 pcs CCFL, 50K hrs, Without Driver |
| Frame Rate |
60Hz |
| Touch Panel |
Without |
| Interface Type |
CMOS (1 ch, 6-bit), 41 pins Connector |
| Power Supply |
3.3/5.0V (Typ.)(VCC) |
| Operating Temperature |
-20 ~ 70 °C |
| Storage Temperature |
-20 ~ 80 °C |
Intended Applications
This module is designed for standard usage in :
-
Industrial control systems and factory automation equipment
-
Test and measurement instruments
-
Office automation equipment
-
Communication devices
-
Transportation equipment (automobiles, ships, trains)
-
POS terminals and kiosks
