Condition: New and orignal , Grade A
Warranty : 1 year
Lead time : 1-3 working days
Shipping : DHL , FEDEX , EMS , UPS ..
| Brand | PVI |
| Model P/N | PD057VU5 |
| Diagonal Size | 5.7" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 320(RGB)×240, QVGA, 70PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 115.2(W) × 86.4(H) mm |
| Bezel Opening | 117.2(W) × 88.4(H) mm |
| Outline Dim. | 144(W) × 104.6(H) × 13.3(D) mm |
| Treatment | Antiglare |
| Luminance | 700 cd/m² (Typ.) |
| Contrast Ratio | 600 : 1 (Typ.) (TM) |
| View Direction | 6 o'clock |
| Response Time | 15/25 ms (Typ.)(Tr/Td) |
| Viewing Angle | 60/60/40/50 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 262K |
| Light Source | WLED [3S12P], 20K hours, Without Driver |
| Weight | 206 ± 10g |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | TTL (1 ch, 6-bit), 33 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -30 ~ 80 °C; Storage Temperature: -40 ~ 85 °C |
This industrial-grade display panel is ideally suited for:
Outdoor Industrial Equipment: Displays for construction machinery, agricultural equipment, and forestry vehicles requiring sunlight readability
Marine and Navigation Systems: Bridge displays and navigation equipment exposed to harsh marine environments
Transportation Terminals: Ticketing kiosks, information displays, and control panels in outdoor transit applications
Cold Chain Logistics: Equipment operating in refrigerated warehouses and cold storage facilities
Oil and Gas Field Equipment: Displays for drilling and extraction equipment in extreme climate locations
Military and Aerospace: Ruggedized displays requiring wide temperature tolerance and high brightness
Industrial Human-Machine Interfaces (HMIs) : Control panels for factory automation in unconditioned spaces
