SCN-AT-FLT15.1-001-0H1
SCN-AT-FLT15.1-001-0H1 is a 15.1-inch 5-wire resistive touch panel, compatible with ELO industrial touch solutions. It features high durability, ≥80% light transmittance, 3H hard coating, and excellent stability, ideal for industrial HMI, medical, and harsh-environment applications.
| Parameter |
Details |
| Model |
SCN-AT-FLT15.1-001-0H1 |
| Technology |
5-wire resistive touch |
| Diagonal Size |
15.1 inches |
| Aspect Ratio |
4:3 |
| Outline Dimensions (W×H) |
320 × 245 mm |
| Active Area (W×H) |
305 × 230 mm |
| Thickness |
1.5 mm (glass) |
| Surface Treatment |
Hard coating (3H hardness), anti-glare |
| Transmittance |
≥80% (ASTM D1003 standard) |
| Linearity Error |
<1.0% |
| Response Time |
<8 ms |
| Resolution |
4096 × 4096 points |
| Operating Force |
25–75 g |
| Lifespan |
≥10 million touches |
| Interface |
FPC (8-pin, 1.25 mm pitch) |
| Cable Length |
80 mm (bottom exit) |
| Operating Temperature |
−20°C ~ +60°C |
| Storage Temperature |
−30°C ~ +70°C |
| Humidity |
10%–90% RH (non-condensing) |
| Certifications |
RoHS compliant, CE |
| Weight |
Approx. 120 g |
