New Touch Screen SG-01
⚙️ General Specifications
Category Specification
Model Number SG01-M150 (typical model)
Product Type Industrial LCD Monitor
Construction Aluminum alloy front panel
Protection Rating NEMA4 / IP65 (front panel)
🖥️ Display Specifications
Parameter Specification
Screen Size Information not specified
Resolution Support Multi-scan: SXGA, XGA, SVGA, VGA, VGA-Text
Brightness High brightness
Touch Screen (Optional) Resistive type (4-wire or 5-wire options available) with COM or USB interface
🔌 Connectivity & Power
Parameter Specification
Video Input RGB (VGA), optional VIDEO input available
Input Voltage 100-240 VAC ±10%, auto-ranging
Output (to monitor) +12 VDC @ 5A (external power supply included)
🌡️ Environmental Specifications
Parameter Specification
Operating Temperature 0°C to 50°C (32°F to 122°F)
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Operating Humidity 10% to 90% @ 40°C, non-condensing (non-touch state)
Vibration Resistance 1G peak, 5-500Hz (random)
Shock Resistance 15G peak acceleration (11ms duration)
📏 Physical & Mounting
Parameter Specification
Mounting Options Panel mount, rack mount, VESA arm mount
Dimensions (WxHxD) Information not specified
Weight Information not specified
📦 Included Accessories
Standard VGA cable
Power cable
12V power supply unit
User manual
Touch screen driver CD (for touch screen models)
