Sharp 18.5 Inch LCD PANEL DISPLAY LQ185M3LW01 use for Industrial
Specifications
| Brand |
Sharp |
Model |
LQ185M3LW01 |
| Size |
18.5 Inch |
Pixel Format |
RGB Vertical Stripe |
| Active Area |
408.96(H)×230.04(V) mm |
Outline Size |
430.4(H)×254.6(V)×11.3(D) mm |
| Brightness |
400cd/m² |
Contrast Ratio |
1500:1 |
| Resolution |
1920(RGB)×1080 |
Lamp |
WLED |
| Surface |
Antiglare, Hard coating |
Frequency |
60HZ |
| Panel Type |
TFT-LCD, LCM |
Touch screen |
Without |
| Signal Interface |
- LVDS (2 ch, 8-bit), 30 pins Connector
|
Environment |
- Operating Temperature -20 ~ 70 °C, Storage Temperature -25 ~ 70 °C
|
Typical Applications
1.Industrial HMI / Human Machine Interface
Factory automation control panels, PLC operation terminals
2.Commercial Display Equipment
Self-service kiosks, vending machine monitors, information inquiry terminals
3.Medical & Testing Instruments
Lab diagnostic equipment, industrial measuring device displays
4.Embedded Industrial Monitors
Machine tool display, security monitoring auxiliary screen
5.Office & Retail Equipment
POS cash register displays, industrial all-in-one PCs
6.Transportation Auxiliary Displays
Non-vehicle onboard fixed monitoring screens, equipment cabin displays
