STCG057QVLAB-G00-S Kyocera 5.7 inch LCD Panel Display For Industrial

Name: STCG057QVLAB-G00-S Kyocera 5.7 inch LCD Panel Display For Industrial
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: STCG057QVLAB-G00-S
Price: 110 USD
Availability: InStock

SKU: STCG057QVLAB-G00-S

Model: STCG057QVLAB-G00-S
Size: 5.7 inch
Resolution: 320(RGB)×240 (QVGA), 70 PPI
Panel Type: a-Si TFT-LCD, Transmissive

0.0 (0 Reviews)

0 Sold

~~$115.00~~ $110.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

STCG057QVLAB-G00-S Kyocera 5.7 inch LCD Panel Display For Industrial

Item	Specification
Model	STCG057QVLAB-G00-S
Brand	Kyocera
Size	5.7 inch (4:3)
Resolution	320(RGB)×240 (QVGA), 70 PPI
Panel Type	a-Si TFT-LCD, Transmissive, TN Normally White
Brightness	300 cd/m² (Typ.)
Contrast Ratio	500:1 (Typ.)
Viewing Angle	80/80/80/80° (L/R/U/D, CR≥5)
Backlight	WLED, 40,000 hrs lifespan, no driver
Interface	Parallel RGB (1 ch, 6-bit), 33 pins
Operating Temp	-20°C ~ +70°C
Storage Temp	-30°C ~ +80°C
Active Area	115.2 × 86.4 mm
Outline Dimension	127.0 × 102.0 × 10.5 mm
Weight	~200g
Surface	Mirror (Haze 0%)
Color Depth	262K colors (6-bit)
Response Time	10/25 ms (Tr/Td)
Input Voltage	3.3V (Typ.)
Compliance	RoHS

Applications

Industrial HMI & Control Panels: PLC interfaces, CNC machines, textile machinery.
Medical Equipment: Patient monitors, diagnostic devices, lab analyzers.
Embedded Systems: Industrial terminals, POS, and data loggers.
Transportation & Machinery: Construction vehicle panels, marine displays.
Office & Automation: Printers, scanners, and factory automation terminals.
