T-51513D104JU-FW-A-AF Kyocera /OPTREX 10.4 Inch 640×480 Industrial TFT LCD Panel For HMI CNC Automation Equipment

Name: T-51513D104JU-FW-A-AF Kyocera /OPTREX 10.4 Inch 640×480 Industrial TFT LCD Panel For HMI CNC Automation Equipment
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: T-51513D104JU-FW-A-AF
Price: 70 USD
Availability: InStock

SKU: T-51513D104JU-FW-A-AF

Model Number: T-51513D104JU-FW-A-AF
Diagonal Size: 10.4 inch (4:3 Aspect Ratio)
Native Resolution: 640(RGB) × 480 VGA, 76 PPI
Panel Technology: a-Si TFT-LCD, TN Normally White Transmissive

0.0 (0 Reviews)

0 Sold

~~$75.00~~ $70.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

T-51513D104JU-FW-A-AF Kyocera /OPTREX 10.4 Inch 640×480 Industrial TFT LCD Panel For HMI CNC Automation Equipment

Item	Specification
Model Number	T-51513D104JU-FW-A-AF
Manufacturer Brand	Kyocera /OPTREX
Diagonal Size	10.4 inch (4:3 Aspect Ratio)
Native Resolution	640(RGB) × 480 VGA, 76 PPI
Panel Technology	a-Si TFT-LCD, TN Normally White Transmissive
Backlight Type	2 Pcs CCFL Lamps, Lifespan 50,000 Hours (No Built-in Inverter)
Typical Brightness	430 cd/m²
Contrast Ratio	600:1 (Typical)
Display Color	262K Colors
Viewing Angle (L/R/U/D)	65°/65°/65°/45° (CR≥10)
Signal Interface	31 Pin Single Channel 6-bit CMOS TTL RGB
Input Voltage	3.3V DC
Response Time (Tr/Td)	9ms / 16ms (Typical)
Display Area	211.2 × 158.4 mm
Overall Outline Size	243 × 181.6 × 12.7 mm
Net Weight	570g (Typical)
Surface Treatment	2H Hard Coating, Anti-Reflective Layer
Operating Temperature	-20℃ ~ +70℃
Storage Temperature	-30℃ ~ +80℃
Core Features	High Brightness, Industrial Wide Temp, Shock Resistant, Plug & Play Replacement
