OPTREX T-51639D084U-FW-A-AA 8.4 inch 1024×768 LCD Panel Display For Industrial
| Parameter |
Specifications |
| Manufacturer |
Kyocera (Optrex) |
| Part Number |
T-51639D084U-FW-A-AA |
| Panel Type |
a-Si TFT-LCD, TN, Normally White, Transmissive |
| Diagonal Size |
8.4 inches |
| Resolution |
1024 (RGB) × 768 (XGA, Landscape) |
| Pixel Format |
RGB Vertical Stripe |
| Active Area |
171.264 mm (W) × 128.448 mm (H) |
| Outline Dimensions |
205(W)×152.4(H) ×11.8(D) mm |
| Thickness |
11.3 ± 0.5 mm |
| Surface Treatment |
Antiglare (Matte), Hard Coating (3H) |
| Brightness |
300 cd/m² (Typical) |
| Contrast Ratio |
350:1 (Typical, Transmissive) |
| Color Depth |
262K colors (6-bit) / 16.7M colors (8-bit) |
| Response Time |
6/19 (Typ.)(Tr/Td) |
| Viewing Angle (CR≥10) |
60/60/50/40 (Typ.)(CR≥10) |
| Refresh Rate |
60 Hz |
| Backlight |
CCFL (2 lamps), Edge type (Top/Bottom), 50K hrs life, No Driver |
| Signal Interface |
LVDS (1 channel, 6/8-bit), 20-pin connector |
| Supply Voltage |
3.3V (Typical) |
| Operating Temperature |
-20°C to +70°C |
| Storage Temperature |
-20°C to +80°C |
| Weight |
380 g (Typical) |
| Touch Screen |
No |
| Status |
Obsolete (Discontinued) |
The T-51639D084U-FW-A-AA is an 8.4-inch XGA industrial LCD module designed for embedded industrial and commercial applications. Its key applications include:
- Industrial HMI & Panel PCs: Operator interface panels for factory automation, PLC control systems, and machinery monitoring.
- Industrial Computers: Embedded computing systems for manufacturing and process control.
- CNC & Machine Tools: Displays for lathes, milling machines, and industrial robotics.
- Portable Medical Monitors: Patient vital signs monitors and compact diagnostic devices.
- Medical Imaging Displays: Small-format displays for ultrasound and portable X-ray equipment.
- In-Vehicle Infotainment: Dashboard displays for commercial vehicles, buses, and trains.
- Marine & Avionics: Navigation and instrumentation screens for non-sunlight critical areas.
- POS Terminals & Kiosks: Compact displays for retail point-of-sale systems and service kiosks.
- Gaming & Amusement Machines: Control panel screens for arcade and slot machines.
- Test & Measurement: Portable oscilloscopes, signal analyzers, and data acquisition systems.
- XGA Resolution (1024×768): Sharp, clear image for detailed graphical interfaces.
- Wide Temperature Range: Reliable operation in harsh industrial environments.
- LVDS Interface: Stable, noise-resistant signal transmission for industrial setups.
- Robust Build: Antiglare hard coating and rugged construction for long-term 24/7 use.
- Compact 8.4-inch Form Factor: Ideal for space-constrained embedded designs.
