OPTREX T-51866D121J-FW-A-AD 12.1 inch 800×600 LCD Panel Screen For Industrial
| Parameter |
Value |
| Manufacturer |
Optrex (Kyocera Display) |
| Model |
T-51866D121J-FW-A-AD |
| Panel Type |
a-Si TFT-LCD, LCM |
| Diagonal Size |
12.1 inches |
| Resolution |
800(RGB) × 600 (SVGA), 82 PPI |
| Display Mode |
TN, Normally White, Transmissive |
| Pixel Arrangement |
RGB Vertical Stripe |
| Active Area |
246.0(W) × 184.5(H) mm |
| Outline Dim. |
280.0(W) × 210.0(H) × 12.0(D) mm |
| Brightness |
350 cd/m² (Typ.) |
| Contrast Ratio |
600:1 (Typ.) |
| Viewing Angle |
80/80/60/80° (Typ., CR≥10) |
| Response Time |
4/12 ms (Tr/Td, Typ.) |
| Color Depth |
262K / 16.7M colors |
| Backlight |
Dual CCFL, 50,000 hrs lifetime |
| Interface |
20-pin LVDS (1 ch, 6/8-bit) |
| Surface |
Hard Coating (2H), Anti-Reflective (AR) |
| Power Supply |
3.3V (Typ.) |
| Operating Temp |
-20°C ~ +70°C |
| Storage Temp |
-20°C ~ +80°C |
| Weight |
770 g (Typ.) |
| Frame Rate |
60 Hz |
| RoHS |
Compliant |
This display is widely used in industrial, medical, and embedded systems requiring reliable, high-visibility performance:
- Industrial Control & HMI: Factory automation panels, PLC interfaces, process monitoring systems.
- Medical Equipment: Patient monitors, diagnostic imaging displays, clinical workstations.
- Test & Measurement: Oscilloscopes, spectrum analyzers, data acquisition systems.
- POS & Retail: Self-service kiosks, cash registers, fast-food order displays.
- Gaming & Amusement: Arcade machines, slot machine displays.
- Automotive & Transportation: In-vehicle infotainment, fleet management screens.
- Marine & Avionics: Navigation displays, control consoles (ruggedized variants).
