Optrex T-51952D065J-FW-A-ABN 6.5 inch 640×480 LCD Display Screen For Industrial

Name: Optrex T-51952D065J-FW-A-ABN 6.5 inch 640×480 LCD Display Screen For Industrial
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: T-51952D065J-FW-A-ABN
Price: 145 USD
Availability: InStock

SKU: T-51952D065J-FW-A-ABN

Model: T-51952D065J-FW-A-ABN
Display Size: 6.5 inches (diagonal)
Display Type: a-Si TFT-LCD, LCM
Resolution: 640 (RGB) × 480 pixels (VGA), 122 PPI

0.0 (0 Reviews)

0 Sold

~~$147.00~~ $145.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

Optrex T-51952D065J-FW-A-ABN 6.5 inch 640×480 LCD Display Screen For Industrial

Parameter	Details
Model	T-51952D065J-FW-A-ABN
Manufacturer	KYOCERA (Optrex)
Display Size	6.5 inches (diagonal)
Display Type	a-Si TFT-LCD, LCM
Resolution	640 (RGB) × 480 pixels (VGA), 122 PPI
Pixel Format	RGB Vertical Stripe
Brightness	600 cd/m² (Typ.)
Contrast Ratio	700:1 (Typ., Transmissive)
Viewing Angle (CR≥10)	70°/70°/50°/60° (L/R/U/D)
Display Mode	TN, Normally White, Transmissive
Surface Treatment	Anti-Glare (AG), Hard Coating (3H)
Display Colors	262K (6-bit)
Response Time	6/19 ms (Tr/Td)
Active Area	132.48 (W) × 99.36 (H) mm
Outline Dimensions	154 (W) × 121 (H) × 7.1/11.5 mm (Typ./Max.)
Dot Pitch	0.207 × 0.207 mm
Panel Weight	205 g (Typ.)
Backlight	2 × CCFL, 50,000 hrs lifespan
Signal Interface	CMOS (1ch, 6-bit), 31-pin connector
Input Voltage (VCC)	3.3 V / 5.0 V
Refresh Rate	60 Hz
Operating Temperature	-20 °C ~ 70 °C
Storage Temperature	-20 °C ~ 80 °C
RoHS Compliance	Yes

Applications

Industrial HMI & Factory Automation: For PLC control panels, industrial PCs, and manufacturing monitoring systems.
Medical Devices: Suitable for diagnostic equipment, patient monitors, and portable medical instruments requiring high reliability.
Outdoor & Rugged Displays: Ideal for outdoor kiosks, transportation terminals, and harsh-environment control interfaces due to high brightness and wide temperature tolerance.
Marine & Vehicle Systems: Used in marine navigation displays, vehicle dashboards, and heavy-duty machinery control panels.
Retail & Hospitality: Applied in point-of-sale (POS) terminals, self-service kiosks, and digital signage for stable performance.
